Description:
Performance C Series
The new Xilence Performance C series is focusing on the essentials. Designed for office and home computers, the new Performance C series delivers stable voltages with high efficiency (ErP2014). This guarantees a considerably low fan noise. Four built-in safety circuits ensure safe operation at all times.
- extremely silent cooling: large 120mm fan
- excellent air flow design for a better heat dissipation
- following safety design:
- Over Voltage Protection (OVP)
- Under Voltage Protection (UVP)
- Short Circuit Protection (SCP)
- Over Load Protection (OLP)
- low stand-by consumption
- complies with ErP2014 norm
Summary: Xilence XP500R6. Total power: 350 W, AC input voltage: 110 – 240 V, Maximum input current (@110V): +12V1,+12V2,+5V,+5Vsb,-12V. Motherboard power connector: 20+4 pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Package type: Box
Vendor Homepage: https://www.xilence.de/en/products/power-supplies/performance-c-series/performance-c-series.html
Category Code: PSU
CnCode: 85044095
Unit Box Height: 0.105
Unit Box Length: 0.23
Unit Box Width: 0.17
AC input voltage: 110 – 240
Max output current (+12V1): 15
Max output current (+12V2): 15
Max output current (+3.3V): 15
Max output current (+5V): 12
Max output current (+5Vsb): 3
Max output current (-12V): 0.3
Power protection features: Over current/Over voltage/Overload/Short circuit/Under voltage
Total power: 350
Cabling type: Non-Modular
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 4
PCI Express power connectors (6+2 pin): 1
ATX version: 2.31
Power supply unit (PSU) form factor: ATX
Purpose: PC
Fan diameter: 120
Number of fans: 1
Product colour: Black
Package type: Box
Harmonized System (HS) code: 84733020
Units per Pallet: 144
Units per Shipping Box: 1
Unit Calculated Volume: 0.004105
Unit Calculated Weight: 1.57
