Description: ROG STRIX B650E-F GAMING WIFI
This mean machine is the heart of your next hot rod. With the stunning speed of PCIe 5.0 and WiFi 6E, hearty cooling from onboard heasinks, and advanced power design engineered for the latest Ryzen™ processors, the ROG Strix B650E-F leaves its competition in the dust.
Vendor Homepage: rog.asus.com/motherboards/rog-strix/rog-strix-b650e-f-gaming-wifi-model/
Model: ROG STRIX B650E-F GAMING WIFI
Chipset: AMD B650
Socket: SAM5
Form Factor: ATX
Memory type: DDR5
Frequency speed: 4800/5200/5400/5600/5800/6000/6200/6400
Memory slots: 4
M.2: 3
PCI-Express 4.0 16x: 1
PCI-Express 4.0 1x: 2
PCI-Express 5.0 16x: 1
Audio port: 5
DisplayPort: 1
HDMI: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 6
USB-C: 2
Bluetooth: Yes
SATA 3.0: Yes
USB 2.0: Yes
USB 3.2: Yes
WiFi: Yes
Integrated video: Depending on CPU
Integrated audio: Realtek ALC4080
Integrated LAN: 2.5 Gigabit
RAID: SATA 0, 1, 10; NVMe 0, 1, 10
Included Accessories: Cables
2 x SATA 6Gb/s cables
Additional Cooling Kit
1 x Thermal pad for M.2
Miscellaneous
1 x ASUS Wi-Fi moving antennas
1 x Cable ties pack
1 x M.2 Q-Latch package
1 x ROG key chain
1 x ROG Strix stickers
1 x ROG Strix thank you card
2 x M.2 Rubber Packages
Documentation
1 x User guide
Units per Shipping Box: 1
Shipping Box Depth: 34
Shipping Box Height: 27.5
Shipping Box Weight: 2.093
Shipping Box Width: 7.5
Unit Calculated Volume: 0.007012
Product Net Weight: 1.7
Unit Calculated Weight: 2.09
CnCode: 84733020
Unit Box Width: 0.075
Unit Box Length: 0.34
Unit Box Height: 0.275
Full Description Line: AMD B650|SAM5|ATX|DDR5|6400/6200/6000/5800/5600/5400/5200/4800 MHz|Memory slots 4|2xPCI-Express 4.0 1x|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|3xM.2|1xHDMI|1xDisplayPort|4xUSB 2.0|6xUSB 3.2|2xUSB-C|1xRJ45|5xAudio port|USB 2.0|USB 3.2|Bluetooth|WiFi|SATA 3.0|Video Depending on CPU|Audio Realtek ALC4080|LAN 2.5 Gigabit|RAID SATA 0, 1, 10; NVMe 0, 1, 10
Category Code: MBA
