Mainboard BIOSTAR AMD B550 SAM4 MicroATX Memory DDR4 Memory slots 4 1xPCI-Express 3.0 1x 1xPCI-Express 3.0 16x 1xPCI-Express 4.0 16x 2xM.2 1x15pin D-sub 1xDVI-D 1xHDMI 2xUSB 2.0 4xUSB 3.2 1xPS/2 1xRJ45 3xAudio port B550MX/EPRO

Description: – Supports AMD Ryzen 3rd Gen (Matisse / Renoir) and 4th Gen (Vermeer) processors
– AMD B550 single chip architecture
– Supports 4-DIMM DDR4-4933+(OC)/4800(OC)/4600(OC)/4400(OC)/4000(OC)/3800(OC)/3600(OC)/3200/2933/2667/2400/2133 up to 128GB maximum capacity
– Supports PCIe M.2 4.0 (64Gb/s)
– Supports HDMI 4K resolution
– Supports WiFi 6 module (No WiFi 6 card included)
Vendor Homepage: www.biostar.com.tw/app/en/mb/introduction.php?S_ID=1011
Model: B550MX/E PRO
Chipset: AMD B550
Socket: SAM4
Form Factor: Micro-ATX
Memory type: DDR4
Frequency speed: 2133/2400/2666/2933/3200/3600/3800/4000/4400
Memory slots: 4
M.2: 2
PCI-Express 3.0 16x: 1
PCI-Express 3.0 1x: 1
PCI-Express 4.0 16x: 1
15pin D-sub: 1
Audio port: 3
DVI-D: 1
HDMI: 1
PS/2: 1
RJ45: 1
USB 2.0: 2
USB 3.2: 4
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
Integrated video: Depending on CPU
Integrated audio: Realtek ALC897
Integrated LAN: Gigabit
TPM: Header
Included Accessories: 2 x SATA Cable;
1 x I/O Shield;
1 x DVD Driver;
1 x Quick Guide;
1 x WiFi antenna accessories
Shipping box quantity: 1
Shipping Box Depth: 28
Shipping Box Height: 6.5
Shipping Box Weight: 0.935
Shipping Box Width: 26
Unit Brutto Volume: 0.004732
Unit Net Weight: 0.6
Unit Gross Weight: 0.935
CnCode: 84733020
Unit Box Width: 0.26
Unit Box Length: 0.28
Unit Box Height: 0.065
Full Description Line: AMD B550|SAM4|Micro-ATX|DDR4|4400/4000/3800/3600/3200/2933/2666/2400/2133 MHz|Memory slots 4|1xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xPCI-Express 4.0 16x|2xM.2|1x15pin D-sub|1xDVI-D|1xHDMI|2xUSB 2.0|4xUSB 3.2|1xPS/2|1xRJ45|3xAudio port|SATA|USB 2.0|USB 3.2|Video Depending on CPU|Audio Realtek ALC897|LAN Gigabit|TPM Header
Category Code: MBA
