Description: GIGABYTE B550M K
AMD B550 Ultra Durable Motherboard with Digital VRM Solution, PCIe 4.0 x16 Slot, Dual PCIe 4.0/3.0 M.2 Connectors, GbE LAN, Smart Fan 5 with FAN STOP
+ Supports AMD Ryzen™ 5000 Series/ Ryzen 5000 G-Series/ Ryzen 4000 G-Series and Ryzen 3000 Series Processors
+ Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs
+ Ultra Durable™ PCIe 4.0 Ready x16 Slot
+ Dual Ultra-Fast NVMe PCIe 4.0/3.0 M.2 Connectors
+ High Quality Audio Capacitors and Audio Noise Guard for Ultimate Audio Quality
+ GbE LAN with Bandwidth Management
+ Rear DisplayPort and HDMI for Multi-display Support
+ Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
+ Anti-Sulfur Resistors Design
The GIGABYTE B550M K motherboard offers a powerful platform for users looking to build a reliable and high-performance system. It is designed to support AMD Ryzen™ 5000 Series, Ryzen 5000 G-Series, Ryzen 4000 G-Series, and Ryzen 3000 Series processors. Here’s a breakdown of its key features:
Processor Support
Compatible with a wide range of AMD Ryzen processors, from the latest Ryzen 5000 series to older 3000 series models, ensuring versatility in terms of CPU selection.
Memory Support
It features dual-channel ECC (Error-Correcting Code) and non-ECC unbuffered DDR4 memory. With four DIMM slots, it allows for a substantial upgrade in memory capacity, enhancing overall system performance.
PCIe 4.0 Ready
The motherboard comes with an Ultra-Durable PCIe 4.0 x16 slot, enabling faster data transfer rates and compatibility with the latest PCIe 4.0 devices like GPUs and NVMe storage drives.
M.2 Storage
Equipped with dual ultra-fast NVMe PCIe 4.0/3.0 M.2 connectors, it supports high-speed storage devices for faster boot times, loading, and file transfers.
Audio and LAN
The high-quality audio capacitors and audio noise guard deliver exceptional sound quality. For networking, it includes a Gigabit Ethernet (GbE) LAN with bandwidth management, ensuring smooth connectivity and data transfer.
Display Ports
The rear I/O includes both DisplayPort and HDMI outputs, offering multi-display support for a flexible visual setup.
Smart Fan 5
Features multiple temperature sensors, hybrid fan headers, and FAN STOP functionality. This ensures the system remains cool and quiet, adjusting fan speeds according to thermal demands.
Anti-Sulfur Resistors Design
This design feature provides greater longevity and stability by preventing damage from sulfur compounds.
The GIGABYTE B550M K motherboard is a robust solution for building an efficient and reliable AMD-based system. It provides excellent performance, great upgrade potential, and a feature-rich design, making it an ideal choice for gaming and productivity setups.
Vendor Homepage: www.gigabyte.com/Motherboard/B550M-K-rev-10#kf
Model: B550M K
Chipset: AMD B550
Socket: SAM4
Form Factor: Micro-ATX
Memory type: DDR4
Frequency speed: 2133/2400/2666/2933/3200/3400/3466/3600/3733/3866/4000/4133/4266/4400/4600/4733
Memory slots: 4
M.2: 2
PCI-Express 3.0 1x: 1
PCI-Express 4.0 16x: 1
Audio-In: 2
Audio-Out: 1
DisplayPort: 1
HDMI: 1
PS/2: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 4
SATA: Yes
Integrated video: Yes
Integrated audio: Yes
Integrated LAN: Gigabit
RAID: SATA 0, 1, 10
TPM: Header
Units per Shipping Box: 1
Shipping Box Depth: 27
Shipping Box Height: 5.5
Shipping Box Weight: 0.777
Shipping Box Width: 27
Unit Calculated Volume: 0.00401
Product Net Weight: 0.62
Unit Calculated Weight: 0.777
CnCode: 84733020
Unit Box Width: 0.27
Unit Box Length: 0.27
Unit Box Height: 0.055
Full Description Line: AMD B550|SAM4|Micro-ATX|DDR4|4733/4600/4400/4266/4133/4000/3866/3733/3600/3466/3400/3200/2933/2666/2400/2133 MHz|Memory slots 4|1xPCI-Express 3.0 1x|1xPCI-Express 4.0 16x|2xM.2|1xHDMI|1xDisplayPort|2xAudio-In|1xAudio-Out|4xUSB 2.0|4xUSB 3.2|1xPS/2|1xRJ45|SATA|Video|Audio|LAN Gigabit|RAID SATA 0, 1, 10|TPM Header
