Description: GIGABYTE X870E AORUS ELITE WIFI7
AMD Socket AM5
Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors
Digital twin
16+2+2 phases VRM solution
Dual Channel DDR5
4*DIMMs with AMD EXPO Memory Module Support
WIFI EZ-Plug
Quick and easy design for Wi-Fi antenna installation
EZ-Latch Plus
PCIe and M.2 slots with Quick Release & Screwless Design
EZ-Latch Click
M.2 heatsinks with screwless design
Sensor Panel Link
Onboard video port for hassle-free in-chassis panel setup
Friendly UI
Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
Ultra-Fast Storage
4*M.2 slots, including 3* PCIe 5.0 x4
Efficient Thermal
VRM Thermal Armor Advanced & M.2 Thermal Guard L
Fast Networking
2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
Extended Connectivity
Dual USB4 Type-C with DP-Alt, HDMI
Reliable Audio
Realtek ALC1220 HD Audio & Audiophile Grade Capacitors
Ultra Durable PCIe Armor
The metal back plate of PCIe x16 slot for enhanced durability
PCIe UD Slot X
PCIe 5.0 x16 slot with 10X strength for graphics card
Vendor Homepage: www.gigabyte.com/Motherboard/X870E-AORUS-ELITE-WIFI7#kf
Model: X870E AORUS ELITE WIFI7 1.2
Chipset: AMD X870E
Socket: SAM5
Form Factor: ATX
Memory type: DDR5
Frequency speed: 4400/4800/5200/5600/6000/6200/6400/6600/6666/6800/7000/7200/7600/7800/8000
Memory slots: 4
M.2: 4
PCI-Express 3.0 4x: 1
PCI-Express 4.0 4x : 1
PCI-Express 5.0 16x: 1
Audio port: 2
HDMI: 1
Optical S/PDIF: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 6
USB-C: 2
Bluetooth: Yes
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
USB-C: Yes
WiFi: Yes
Integrated video: Depending on CPU
Integrated audio: Realtek ALC1220
Integrated LAN: 2.5 Gigabit
RAID: SATA 0, 1, 10
TPM: Header
Units per Shipping Box: 5
Shipping Box Depth: 45
Shipping Box Height: 37.7
Shipping Box Weight: 13.15
Shipping Box Width: 31.4
Unit Calculated Volume: 0.01065
Product Net Weight: 2.2
Unit Calculated Weight: 2.63
CnCode: 84733020
Unit Box Width: 0.272
Unit Box Length: 0.082
Unit Box Height: 0.334
Full Description Line: AMD X870E|SAM5|ATX|DDR5|8000/7800/7600/7200/7000/6800/6666/6600/6400/6200/6000/5600/5200/4800/4400 MHz|Memory slots 4|1xPCI-Express 3.0 4x|1xPCI-Express 4.0 4x |1xPCI-Express 5.0 16x|4xM.2|1xHDMI|4xUSB 2.0|6xUSB 3.2|2xUSB-C|1xOptical S/PDIF|1xRJ45|2xAudio port|SATA|USB-C|USB 2.0|USB 3.2|Bluetooth|WiFi|Video Depending on CPU|Audio Realtek ALC1220|LAN 2.5 Gigabit|RAID SATA 0, 1, 10|TPM Header
Category Code: MBA
