Description: MAG Z890 TOMAHAWK WIFI is designed for gamers with a stable, durable and DIY friendly foundation for their PC builds. Coming up with Killer Wi-Fi 7 solution and 5G LAN, Thunderbolt 4, PCIe 5.0 solutions, Supplemental PCIe Power and exclusive EZ DIY features, it's ready for the battlefied of Intel Core Ultra processors.
– Support Intel® Core™ Ultra Processors (Series 2) for LGA 1851 socket
– Supports DDR5 Memory, Dual Channel DDR5 9200+ MT/s (OC)
– Ultra Performance: 16+1+1+1 Duet Rail Power System 90A SPS, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB made by 2oz thickened copper and server-grade level material
– Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
– EZ DIY: EZ PCIe Release, EZ M.2 Shield Frozr II, EZ M.2 Clip II and EZ Antenna
– Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
– Ultra Connect: Thunderbolt™ 4 port, Intel® Killer™ 5G LAN & Intel® Killer™ Wi-Fi 7 Solution – the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
– Audio Boost 4: Reward your ears with studio grade sound quality for the most immersive gaming experience
Vendor Homepage: www.msi.com/Motherboard/MAG-Z890-TOMAHAWK-WIFI
Model: MAG Z890 TOMAHAWK WIFI
Chipset: Intel Z890
Socket: LGA1851
Form Factor: ATX
Memory type: DDR5
Frequency speed: 4800/6400/7200/9200
Memory slots: 4
M.2: 4
PCI-Express 4.0 4x : 2
PCI-Express 5.0 16x: 1
Audio port: 2
HDMI: 1
Optical S/PDIF: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 3
USB-C: 1
USB-C w/Thunderbolt: 2
Bluetooth: Yes
SATA: Yes
Thunderbolt: Yes
USB 2.0: Yes
USB 3.2: Yes
USB-C: Yes
WiFi: Yes
Integrated video: Depending on CPU
Integrated LAN: 5 Gigabit
Integrated audio: Realtek ALC1220P
RAID: SATA 0, 1, 5, 10; NVMe 0, 1, 5, 10
Units per Shipping Box: 5
Shipping Box Depth: 38
Shipping Box Height: 37
Shipping Box Weight: 11.3
Shipping Box Width: 28.5
Unit Calculated Volume: 0.008014
Product Net Weight: 2
Unit Calculated Weight: 2.26
CnCode: 84733020
Unit Box Width: 0.27
Unit Box Length: 0.345
Unit Box Height: 0.072
Full Description Line: Intel Z890|LGA1851|ATX|DDR5|9200/7200/6400/4800 MHz|Memory slots 4|2xPCI-Express 4.0 4x |1xPCI-Express 5.0 16x|4xM.2|1xHDMI|4xUSB 2.0|3xUSB 3.2|1xUSB-C|2xUSB-C w/Thunderbolt|1xOptical S/PDIF|1xRJ45|2xAudio port|SATA|USB-C|USB 2.0|USB 3.2|Thunderbolt|Bluetooth|WiFi|Video Depending on CPU|LAN 5 Gigabit|Audio Realtek ALC1220P|RAID SATA 0, 1, 5, 10; NVMe 0, 1, 5, 10
Category Code: MBI
