Description:
- AMD Socket AM5：Supports AMD Ryzen 7000/ Ryzen 8000 Series Processors
- Unparalleled Performance：Twin 12+2+2 Phases Digital VRM Solution
- Dual Channel DDR5：4*DIMMs with AMD EXPO & Intel® XMP Memory Module Support
- Superfast Storage：1*PCIe 5.0 x4 and 2*PCIe 4.0 x4 M.2 Connectors
- Advanced Thermal Design & M.2 Thermal Guard ：To Ensure VRM Power Stability & 25110 M.2 SSD Performance
- EZ-Latch：PCIe x16 Slot & M.2 Connectors with Quick Release & Screwless Design
- Fast Networks：2.5GbE LAN & Wi-Fi 6E
- Extended Connectivity：HDMI, DP, Front USB-C® 20Gb/s, Rear USB-C 10Gb/s
- Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card
Vendor Homepage: www.gigabyte.com/Motherboard/B650-AORUS-ELITE-AX-ICE
Category Code: MBA
CnCode: 84733020
M.2: 3
PCI-Express 16x: 1
PCI-Express 3.0 16x: 2
Audio port: 3
DisplayPort: 1
HDMI: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 7
USB-C: 1
Bluetooth: Yes
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
USB-C: Yes
WiFi: Yes
Model: B650 A ELITE AX ICE
Chipset: AMD B650
Socket: SAM5
Form Factor: ATX
Memory type: DDR5
Frequency speed: 4400/4800/5200/5600/6000/6200/6400/6600/6666/6800/7000/7200/7600/7800/8000
Memory slots: 4
Integrated video: Depending on CPU
Integrated LAN: 2.5 Gigabit
RAID: SATA 0, 1, 10; NVMe 0, 1, 10
TPM: Header
Units per Shipping Box: 1
Unit Calculated Volume: 0.007344
Product Net Weight: 0.97
Unit Calculated Weight: 2
