Description:
- Supports Intel® Core™ Ultra processors (Series 2)
- Hybrid 3+1+2 phases VRM solution
- EZ-Latch: PCIe x16 Slot with Quick Release Design
- Friendly UI: Multi-Theme and Q-Flash Auto Scan in BIOS and SW
- Next Generation Storage: PCIe 4.0 x4 M.2 Connectors
- Fast Networking: GbE LAN
- Extended Connectivity: HDMI, DisplayPort
Vendor Homepage: www.gigabyte.com/Motherboard/H810M-K
Category Code: MBI
CnCode: 84733020
Unit Box Height: 0.055
Unit Box Length: 0.265
Unit Box Width: 0.235
M.2: 1
PCI-Express 3.0 1x: 1
PCI-Express 4.0 16x: 1
Audio port: 3
DisplayPort: 1
HDMI: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 2
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
Model: H810M K
Chipset: Intel H810
Socket: LGA1851
Form Factor: Micro-ATX
Memory type: DDR5
Frequency speed: 5600/6400
Memory slots: 2
Integrated video: Depending on CPU
Integrated LAN: Gigabit
Integrated audio: Yes
RAID: SATA 0, 1, 5, 10
TPM: Header
Units per Pallet: 0
Units per Shipping Box: 1
Unit Calculated Volume: 0.003425
Product Net Weight: 0.58
Unit Calculated Weight: 0.687
