Description: 1/3” 4 Megapixel progressive CMOS, 2560 × 1440 @20 fps
2.8 mm fixed lens (90 °)
Min. Illumination: 0.025 lux@ F2.0 (Color,30 IRE); 0.0025 lux@ F2.0 (B/W,30 IRE); 0 lux (Illuminator on)
Up to 30 meters IR Illumination
True Day/Night with ICR Filter, BLC, HLC, DWDR, 3D DNR
Smart H.265+; Smart H.264+, H.264B; H.264; H.264H; H.265, ONVIF (Profile S/Profile G); CGI; P2P
Wi-Fi: IEEE802.11b/g/n 2.4~2.4835GHz, up to 80 m
Built-in MIC, Micro SD Slot (up to 256 GB)
DC 12V1A Power supply, Power Consumption: < 4.1W
Bullet design, metal case, IP67, -40°C to +50°C, indoor/outdoor use
Free IP monitoring software available
Vendor Homepage: https://www.dahuasecurity.com/ea/products/All-Products/Network-Cameras/Wireless-Series/Wi-Fi-Series/4MP/IPC-HFW1430DS-SAW
Camera design: Bullet
Network Camera Type: HDTV/Megapixel/Outdoor
Pixel Resolution: 4
Focal Length: 2.8 mm
IR Illumination: Yes
Sensor size: 1/3”
Microphone: Built-in
Lens Mount: M12
Effective pixels: 2560(H)×1440(V)
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
MicroSD Card Slot: 1
Power options: 12V
Power supply requirements: 12 VDC
Operating temperature range: –40 °C to +60 °C
Dimensions: 166.2 mm × 70.0 mm × 128.6 mm
Shipping box quantity: 1
Shipping Box Depth: 23.5
Shipping Box Height: 10.5
Shipping Box Weight: 0.73
Shipping Box Width: 12.5
Unit Brutto Volume: 0.003084
Unit Net Weight: 0.477
Unit Gross Weight: 0.73
CnCode: 85258900
Unit Box Width: 0.125
Unit Box Length: 0.235
Unit Box Height: 0.105
Full Description Line: Type HDTV/Megapixel/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/3”|Microphone Built-in|Lens Mount M12|Effective pixels 2560(H)×1440(V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xMicroSD Card Slot|Power options 12V|Power supply requirements 12 VDC|Operating temperature range –40 °C to +60 °C|Dimensions 166.2 mm × 70.0 mm × 128.6 mm
Category Code: FNC
