Description:
Specifically designed for onboard surveillance, AXIS P3925-R complies with all relevant transportation industry regulations including EN50155, EN45545, and NFPA 130. Featuring Axis Lightfinder and Axis Forensic WDR, it delivers true colors and great detail in challenging light or near darkness. Enclosed in an IK10-, IP66-, IP67-rated metal casing, this robust, vandal-resistant camera offers extended capabilities for analytics. Furthermore, enhanced security features prevent unauthorized access and safeguard your system.
- Complies with EN50155, EN45545, and NFPA 130; Electronic image stabilization; Enhanced security features; Lightfinder and Forensic WDR; Vandal-resistant, metal casing
Summary: Axis 01933-001. Type: IP security camera, Connectivity technology: Wired, PTZ modes: Digital PTZ. Mounting type: Ceiling, Product colour: Black, White, Form factor: Dome. Minimum illumination: 0.01 lx, Angle of rotation: 350°, Lens viewing angle, horizontal: 110°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9″). Fixed focal length: 2.8 mm
Vendor Homepage: https://www.axis.com/products/axis-p3925-r
Category Code: FNC
CnCode: 85258900
Unit Box Height: 0.085
Unit Box Length: 0.165
Unit Box Width: 0.12
Fog proof: Yes
Form factor: Dome
Housing material: Aluminium
IK code: IK10
International Protection (IP) code: IP66, IP67
Mounting type: Ceiling
Product colour: Black/White
Certification: 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, EN 50121-4, EN 50121-3-2, IEC 62236-4, ECE R10 rev.05 (E approval), EN 50498, IEC/EN
Connectivity technology: Wired
Day/night mode: Yes
Preset points: Yes
PTZ control: Yes
PTZ modes: Digital PTZ
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Angle of rotation: 350
Camera pan control: Yes
Camera shutter speed: 1/33500 – 2
Camera tilt control: Yes
Lens viewing angle, horizontal: 110
Lens viewing angle, vertical: 62
Minimum illumination: 0.01
Pan range: -30 – 30
Tilt angle range: 15 – 90
Number of sensors: 1
Optical sensor size: 1/2.9
Progressive scan: Yes
Sensor type: CMOS
Fixed focal length: 2.8
Maximum aperture number: 1.6
Number of lenses: 1
Bit rate control: Variable Bit Rate (VBR)
Frame rate: 45
Image quality adjustment: Brightness/Contrast/Sharpness
Image stabilizer: Yes
Maximum resolution: 1920 x 1080
Privacy masking: Yes
Supported graphics resolutions: 1280 x 960/160 x 120/160 x 90/1920 x 1080 (HD 1080)
Text caption overlay: Yes
Video compression formats: AVC/H.264/H.265/HEVC/M-JPEG/MPEG4
Video streaming: Yes
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Networking standards: IEEE 802.1x/IEEE 802.3af/IEEE 802.3at
Number of users: 8
Quality of Service (QoS) support: Yes
Streaming method: Multicast
Supported network protocols: IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC
Flash memory: 512
Ethernet LAN (RJ-45) ports: 1
Active tampering alarm: Yes
HTTPS encryption: Yes
IP address filtering: Yes
Password protection: Yes
Video motion detection: Yes
Power consumption (max): 6.4
Power consumption (typical): 4.2
Power source type: PoE
Operating relative humidity (H-H): 10 – 95
Operating temperature (T-T): -40 – 55
Storage temperature (T-T): -40 – 65
Depth: 110
Height: 49.5
Weight: 410
Width: 110
Number of cameras: 1
Harmonized System (HS) code: 85258900
Units per Shipping Box: 1
Unit Calculated Volume: 0.001683
Unit Calculated Weight: 0.55
