Description:
•32 IP channel max, up to 32MP resolution
• up to 384 Mbps incoming bandwidth
•VGA/HDMI up to 3840 × 2160 output
•2 SATA interface up to 16 TB each
•No front panel controls, 4/2 alarm I/O, RS232, RS485, 2 USB
•1U 19” chassis, mouse included
•Free IP monitoring software available
•Smart capabilities support: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
• Support AcuPick with Max. 16-Channel
Vendor Homepage: www.dahuasecurity.com/ceen/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI-Series/2HDD/NVR5232-EI
Category Code: NVR
CnCode: 85219000
Unit Box Height: 0.36
Unit Box Length: 0.43
Unit Box Width: 0.14
Desktop/pedestal: Yes
Rack 1U: Yes
SATA: Yes
15pin D-sub: 1
HDMI: 1
Audio-In: 1
Audio-Out: 1
RS232: 1
USB 2.0: 1
USB 3.0: 1
RJ45: 1
RS-485: 1
Alarm In: 4
Alarm Out: 2
Number of Channels: 32
Number of drives/bays: 2
CPU: Embedded Linux
Power supply requirements: 12 VDC, 4 A
Power consumption: 10
Dimensions: 375.0 × 284.4 x 56.0mm
Units per Shipping Box: 1
Unit Calculated Volume: 0
Product Net Weight: 2
Unit Calculated Weight: 3
