Description:
The Eaton 9E UPS constantly monitors power conditions and regulates voltage and frequency thanks to the double conversion topology. Eaton 9E UPS can power more servers than most similar UPS because of a 0.8 power factor.
- Get clear information on the UPS’ status and measurements (load level, battery level, input/output voltage and frequency) on a single screen with the new LCD interface
- Easily communicate with the UPS through USB, RS232 serial or over the network with the optional network card (Network-MS). Relay cards or Modbus cards are also available
- Integrate 9E into all software environments. The Eaton 9E is delivered with Eaton’s Intelligent Power™ Software and is compatible with all major OS including advanced integration in VMware vCenter and Microsoft Hyper-V
- Wide input voltage range will minimize the battery usage and help to extend battery lifetime
- The internal bypass allows service continuity in case of an internal fault
- Extend runtime as you like by adding up to 4 external battery modules (EBM) for 2kVA and above. For extra-long runtime, XL models with internal supercharger are also available at 3kVA
Summary: Eaton 9E 2000I. UPS topology: Double-conversion (Online), Output power capacity: 2 kVA, Output power: 1600 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C13 coupler, AC outlets quantity: 6 AC outlet(s). Typical backup time at full load: 4 min, Typical backup time at half load: 12 min. Form factor: Tower, Product colour: Black. Certification: IEC/EN 62040 -2, CE, CB report (TUV)
Vendor Homepage: https://powerquality.eaton.com/Products-services/Backup-Power-UPS/9E-1-3kVA.aspx?cx=41&GUID=482418BF-1164-410A-AEB9-A0ED9FA7A642
Category Code: UPW
CnCode: 85044095
Unit Box Height: 0.46
Unit Box Length: 0.495
Unit Box Width: 0.33
Efficiency: 91
Input frequency: 50/60
Input operation voltage (max): 300
Input operation voltage (min): 100
Noise level: 40
Output frequency: 50/60
Output operation voltage (max): 240
Output operation voltage (min): 208
Output power: 1600
Output power capacity: 2
UPS topology: Double-conversion (Online)
AC outlet types: C13 coupler/C19 coupler
AC outlets quantity: 6
Power plug: C13 coupler
RS-232 ports: 1
Serial interface: Yes
Serial interface type: RS-232
Serial ports quantity: 1
USB port: Yes
Typical backup time at full load: 4
Typical backup time at half load: 12
Form factor: Tower
Product colour: Black
Operating temperature (T-T): 0 – 40
Certification: IEC/EN 62040 -2, CE, CB report (TUV)
Safety: IEC/EN 62040-1
Depth: 190
Height: 399
Weight: 22400
Width: 330
Units per Shipping Box: 1
Unit Calculated Volume: 0.07514
Unit Calculated Weight: 23.1
