Description:
Modern and futuristic, with the attractive specifications and perfect balance, the Race Sport (RS) Edition is the evolution of the most popular PRO series motherboard.
Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors
8+2+1 Phase Power Design, Dr.MOS for VCore+SOC+MISC
4 x DDR5 DIMMs
Supports Dual Channel, up to 8000+ (OC)
1 PCIe 5.0 x16, 1 PCIe 4.0 x4
Graphics Output Options: 1 HDMI, 1 DisplayPort
Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
1 Blazing M.2 (PCIe Gen5x4)
2 Hyper M.2 (PCIe Gen4x4)
4 SATA3
1 USB 3.2 Gen2 Type-C (Rear)
1 USB 3.2 Gen2 Type-A (Rear)
1 USB 3.2 Gen1 Type-C (Front)
6 USB 3.2 Gen1 (2 Rear, 4 Front)
8 USB 2.0 (4 Rear, 4 Front)
Realtek 2.5G LAN
802.11axe WiFi 6E +Bluetooth
Supports M.2 Bottom Heatsink, BIOS Flashback
Vendor Homepage: www.asrock.com/mb/AMD/B850M%20Pro%20RS%20WiFi/index.asp
Category Code: MBA
CnCode: 84733020
Unit Box Height: 0.06
Unit Box Length: 0.3
Unit Box Width: 0.265
PCI-Express 4.0 4x : 1
PCI-Express 5.0 16x: 1
M.2: 1
HDMI: 1
DisplayPort: 1
Audio-In: 1
Audio-Out: 1
Microphone: 1
USB 2.0: 4
USB 3.2: 3
USB-C: 1
RJ45: 1
SATA: Yes
USB-C: Yes
USB 2.0: Yes
USB 3.2: Yes
Bluetooth: Yes
WiFi: Yes
SATA 3.0: Yes
Model: B850M Pro RS WiFi
Chipset: AMD B850
Socket: SAM5
Form Factor: Micro-ATX
Memory type: DDR5
Frequency speed: 8000
Memory slots: 4
Integrated video: Depending on CPU
Integrated audio: Realtek ALC897
Integrated LAN: 2.5 Gigabit
RAID: SATA 0, 1, 10
TPM: Header
Units per Shipping Box: 10
Unit Calculated Volume: 0
Product Net Weight: 1
Unit Calculated Weight: 1
