INFINITY MIRROR FAN
A combination of the original UNI FAN SL and AL with a touch of infinity mirror, the SL-Infinity fans glow clear with multi-layer effects from any visible angle.
CENTERED INFINITY MIRROR ARGB
The circular-shaped infinity mirror at the center of the fan is tuned to have multiple layers spaced 0.5mm apart.
SIDE FRAME ARGB
Following the iconic angular lighting style of SL fans, the SL-Infinity fans have 2 thin LED strips on both sides of the fan blade.
ALUMINUM TRIM SURROUNDED INFINITY MIRROR
Surrounding aluminum trims are located on both sides of the frame. The geometric shape of the infinity mirror follows the front ARGB lighting strip in a top and bottom pattern that creates a 3D indented look.
REAR RIM OF LED AROUND THE ALUMINUM LOGO
Inspired by AL fans, there is a bright ARGB rim of light around the LIAN LI logo at the rear.
DAISY CHAIN FAN
A pin-to-pad contact point passes the signal and power through the fan cluster.
- Acoustic noise 29 dB(A) Max
- 120 mm
- Infinity Mirror effect
- 3 x fan
| Summary | Lian Li Uni Fan SL-INF. Type: Fan, Fan diameter: 12 cm, Rotational speed (max): 2100 RPM, Maximum air pressure: 2.66 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Product colour: White |
|---|---|
| Vendor Homepage | https://lian-li.com/product/uni-fan-sl-infinity/ |
| Category Code | COS |
| Unit Box Height | 0.15 |
| Unit Box Length | 0.16 |
| Unit Box Width | 0.1 |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Fan diameter | 120 mm |
| Maximum air pressure | 2.66 mmH2O |
| Maximum airflow | 61.3 cfm |
| Noise level (high speed) | 29 dB |
| Quantity per pack | 3 pc(s) |
| Rotational speed (max) | 2100 RPM |
| Suitable location | Computer case |
| Type | Fan |
| Fan connector | 4-pin |
| Illumination colour | Multi |
| Illumination LED | Yes |
| LED connector type | 3-pin |
| Number of LEDs | 40 |
| Product colour | White |
| Fan current | 0.18 A |
| LED voltage | 5 V |
| Starting voltage | 6 V |
| Voltage | 12 V |
| Fan dimensions (W x D x H) | 120 x 122.1 x 25 mm |
| Fan thickness | 25 mm |
| Model | UNI FAN SL INFINITY 120 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.0024 cubm |
| Unit Calculated Weight | 0.899 kg |
