Description:
Finally, a Micro-ATX with Great Cooling
The AIR 100 series is the first Micro-ATX case from Montech’s acclaimed AIR Series PC cases. Its smaller footprint makes easy to carry and takes much less space.
Despite its smaller form factor the AIR 100 cuts no corners to achieve the best cooling capacity capable. Expandability and anti-dust features also adhere to Montech’s AIR Series standard. Combining this all with a clean minimalist design, the AIR 100 provides PC users a smooth and classy but also high performance build experience.
Dust Resistant & Airflow Optimized Front Panel
The Super Fine Mesh Face Plate not only provides unobstructed cool airflow into the case, it also acts as an anti-dust cover. With its smart quick release design, removing the Super Fine Mesh for cleaning is simple and tool free.
Ultra-Minimalist Design
The cleverly designed top cover design and the Super Fine Mesh Face Plate molds into one unified clean minimalist style language.
Cool Your Build
The two pre-installed high quality system fans are located at the front and back of the system in push pull configuration for optimal cooling performance.
More Convenient & More Safe
The unique Side Swivel Tempered Glass Side Panel design is not only easier for users to unmount, its zero drill-hole design drastically improves the panel’s strength integrity and safety.
Enjoy Building Your PC
Although a class smaller in volume, nothing is sacrificed in terms of expandability. The AIR 100 ARGB supports GPU cards up to 330mm, 160mm PSUs and tower heatsinks up to 161mm. 280mm radiators can be mounted at the front, while at the top there’s space for 240mm radiators. The AIR 100 Lite is expansion capable for years to come.
Smart Cable Management
With cable management in-mind, the AIR 100 ARGB has strategically pre-installed cable loops and Velcro straps. This makes building your system with good clean cable management a breeze.
Easy Accessible I/O Ports
Two high-speed USB 3.0, a USB 2.0 and the HD Audio ports are all located on the top of the case for easy accessibility.
Drive Bays
– II 3.5″ HDD or 2.5″ SSD x 2
– I 2.5″ SSD x 5
Clearance
– I PSU Length~160mm
– I CPU Cooler Height~161mm
– I GPU Card Length~330mm
Versatile Cooling Options
– Fan Support
– I Top 120mm x 2 / 140mm x 2
– I Front 120mm x 3 / 140mm x 2
– I Inside 120mm x 2
– I Rear 120mm x 1
– Radiator Support
– I Top 120 / 140 / 240mm
– I Front 120 / 140 / 240 / 280mm
– I Rear 120mm
Motherboard Support
– Radiator Support
– I Micro – ATX
– I Mini-ITX
Total Dust Protection
The fine mesh front panel acts as an anti-dust cover, alone with top and bottom dust filters to prevent any dust infiltration.
- Super Fine Mesh Face Plate
- Enhanced Thermal Performance
- Meets Simplistic Minimalist Design
- Two High Quality System Fans Included
- Side Swivel Tempered Glass Side Panel
- Expansion Capable
Summary: Montech Air 100 LITE. Form factor: Desktop, Type: PC, Product colour: Black. Front fans installed: 1x 120 mm, Front fans diameters supported: 120,140 mm, Rear fans installed: 1x 120 mm. Supported HDD sizes: 3.5″, SSD form factor: 2.5″. Width: 405 mm, Depth: 210 mm, Height: 425 mm
Vendor Homepage: https://www.montechpc.com/air-100-lite
Category Code: CAS
CnCode: 84733080
Unit Box Height: 0.49
Unit Box Length: 0.49
Unit Box Width: 0.29
Anti-dust filter: Yes
Form factor: Desktop
Maximum CPU cooler height: 161
Maximum graphics card length: 330
Maximum PSU length: 160
Number of 2.5″ bays: 4
Number of 3.5″ bays: 2
On/off button: Yes
Product colour: Black
RGB control button: Yes
Supported motherboard form factors: micro ATX/Mini-ITX
Type: PC
Power supply included: No
Audio output: Yes
Combo headphone/mic port: Yes
USB 2.0 ports quantity: 1
USB 3.0: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Front fans diameters supported: 120/140
Front fans installed: 1x 120 mm
Front radiator sizes supported: 120/140/240/280
Number of front fans supported (max): 3
Number of rear fans supported (max): 1
Number of top fans supported (max): 2
Rear fans diameters supported: 120
Rear fans installed: 1x 120 mm
Rear radiator sizes supported: 120
Top fans diameters supported: 120/140/240
Top fans installed: 2x 120 mm
Number of HDDs supported: 2
SSD form factor: 2.5″
Supported HDD sizes: 3.5
Depth: 210
Height: 425
Width: 405
Model name: AIR 100 LITE
Units per Shipping Box: 1
Unit Calculated Volume: 0.06963
Unit Calculated Weight: 6.65
