Description:
UHD Signage Display with LG webOS Platform and Advanced Security
Superb Picture Quality with Ultra HD Resolution
With the resolution of UHD, it makes the colors and details of the content vivid and realistic. In addition, the wide viewing angle provides clear content.
Even & Slim Bezel Design
The UH5Q series features perfectly balanced horizontal and vertical slim bezels, creating a visually harmonious display solution. Its specialized design simplifies installation in retail environments while delivering a truly immersive viewing experience.
Convenient webOS Platform
The UH5Q is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, and includes webOS partner apps to create an SI-friendly environment.
* SoC : System On Chip
** SI : System Integrator
Design for Space Utilization
Designed with thin bezels and simple cable management, the UH5Q saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13.5 mm of space with the slim bracket.
* The product image will differ slightly from the actual appearance of the product due to the variance caused by each inch option.
Durability that Provides Reliability
Optimized for business environments, the UH5Q is protected against salt, dust, iron powder and humidity thanks to conformal partial coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring*, provide both reliability and satisfaction.
* When a physical impact occurs on the product, an alert is provided to the administrator through the media controller.
Comprehensive Security
webOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also webOS platform support ETSI EN 303 645.
SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
* SuperSign must be purchased separately.
Summary: LG 43UH5Q. Product design: Digital signage flat panel. Display diagonal: 109.2 cm (43″), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Vendor Homepage: https://www.lg.com/global/business/digital-signage/lg-43uh5q
Category Code: LCD
CnCode: 85285291
Unit Box Height: 0.66
Unit Box Length: 1.05
Unit Box Width: 0.135
Colour depth: 10
Colour gamut: 95
Contrast ratio (dynamic): 1000000:1
Contrast ratio (typical): 1200:1
Display brightness: 500
Display diagonal: 43
Display number of colours: 1.07 billion colours
Display resolution: 3840 x 2160
Display technology: LCD
HD type: 4K Ultra HD
LED backlight: Yes
LED backlighting type: Edge-LED
Native aspect ratio: 16:9
Native refresh rate: 60
Panel life: 50000
Panel type: ADS
Response time: 8
Touchscreen: No
Viewing angle, horizontal: 178
Viewing angle, vertical: 178
DisplayPorts in: 1
DisplayPorts quantity: 1
DVI port: No
Ethernet LAN (RJ-45) ports: 1
HDMI input ports quantity: 3
HDMI ports quantity: 3
PC Audio out: Yes
Remote (IR) input: 1
RS-232C: Yes
USB connector type: USB Type-A
USB port: Yes
USB ports quantity: 2
USB version: 2.0
Built-in speaker(s): Yes
Number of built-in speakers: 2
RMS rated power: 20
Bezel colour: Black
Orientation: Horizontal/Vertical
Panel mounting interface: 200 x 200
Placement supported: Indoor
Product colour: Black
Product design: Digital signage flat panel
VESA mounting: Yes
Automatic brightness control: Yes
HDCP: Yes
HDCP version: 1.4/2.2
International Protection (IP) code: IP5X
Number of OSD languages: 21
On Screen Display (OSD): Yes
Operating hours (hours/days): 24/7
Picture-in-Picture: Yes
Purpose: Universal
Smart modes: Energy saving
AC input frequency: 50/60
AC input voltage: 100 – 240
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): G
Heat dissipation: 222
Power consumption (max): 124
Power consumption (off): 0.5
Power consumption (standby): 0.5
Power consumption (typical): 65
Computer system: Yes
Computer system type: System on Chip (SoC)
Internal memory: 16
Operating system installed: WebOS
Operating system version: webOS 8.0
Display depth: 29.7
Display height: 561
Display weight: 9400
Display width: 971.7
Package depth: 140
Package height: 660
Package weight: 11300
Package width: 1055
Batteries included: Yes
Cables included: AC
Remote control included: Yes
Operating relative humidity (H-H): 10 – 80
Operating temperature (T-T): 0 – 40
Certification: CB / NRTL / FCC Class “B” / CE / KC
Ethernet LAN: Yes
Security algorithms: SNMP
Wi-Fi: Yes
Heat dissipation (max): 423
Real Time Clock (RTC): Yes
Surface treatment: 25%
Sustainability certificates: ENERGY STAR/ErP
Bezel width: 11.4
Built-in brightness sensor: Yes
Plug and Play: Yes
Power consumption (PowerSave): 46
Power supply type: Internal
Data Sheet (Link): https://eprel.ec.europa.eu/api/product/2406049/fiches?language=EN
Energy efficiency class: G
EPREL Registration Number: 2406049
EPREL Version Number: 1.001
Model: 43UH5Q-E
Unit Calculated Volume: 0.093555
Unit Calculated Weight: 11.5
