Description:
Reverse Spin
The center fan spins reversely to lower turbulence and enhance air dispersion through the heatsink.
Taichi 3X Cooling System
Crafted for the best balance between the thermal efficiency and silence by all the details improved.
Striped Ring Fan
Designed For Enhanced Airflow
ASRock’s all new Striped Ring Fan get more lateral intake and to provide better airflow through the cooling array.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Air Deflecting Fin
Guide Airflow to Go Through Regularly & Quickly.
Guide the airflow to go more regularly and quickly to enhance the cooling efficiency by the V-shaped cutting fins and the V-shaped air vents.
Ultra-fit Heatpipe
Consolidated to Maximize the Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Nickel-plated Copper Base
Maximize GPU Contact Area.
With premium copper base heatsink design, the direct contact area to the GPU would be maximized to improve thermal transfer effectively.
High-density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Honeywell PTM7950
Phase-change Thermal Pad
Honeywell PTM7950 phase-change thermal pad can effectively fill the gaps between the GPU and the thermal module, enabling the graphics card to provide excellent heat dissipation, reliability and longevity under high loads.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
Polychrome SYNC
Create your own unique colorful light effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
LED Switch
Switch on/off as you want.
You can switch LED on or off depends on the scenarios or your need.
ARGB Pin-header
More ARGB, More Fancy.
With the ARGB pin-header, it can connect ARGB strips/devices to make the lighting effects more rich and vivid.
16 Power Phase Design with SPS
More Power Phase Equipped to Deliver More Sufficient Power.
Featuring 16 power phases with SPS components to raise maximum current to GPU and memory to offer enhanced performance.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Dual BIOS
Dual BIOS design allows users choose preferred setting by switching between the P(Performance) BIOS and Q(Quiet) BIOS.
Summary: Asrock Taichi AMD Radeon RX 9070 XT 16GB OC. Graphics processor family: AMD, Graphics processor: Radeon RX 9070 XT. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR6, Memory bus: 256 bit. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express x16 5.0. Cooling type: Active, Number of fans: 3 fan(s)
Vendor Homepage: https://www.asrock.com/Graphics-Card/AMD/Radeon%20RX%209070%20XT%20Taichi%2016GB%20OC/index.asp#Overview
Category Code: VGP
CnCode: 84718000
CUDA: No
Graphics processor: Radeon RX 9070 XT
Graphics processor family: AMD
Maximum displays per videocard: 4
Maximum resolution: 7680 x 4320
Processor boost clock speed: 3100
Processor boost clock speed (Gaming mode): 2750
Stream processors: 4096
Data transfer rate: 20
Discrete graphics card memory: 16
Graphics card memory type: GDDR6
Memory bus: 256
DisplayPort version: 2.1a
DisplayPorts quantity: 3
HDMI ports quantity: 1
HDMI version: 2.1b
Interface type: PCI Express x16 5.0
DirectX version: 12 Ultimate
Dual Link DVI: No
HDCP: Yes
OpenGL version: 4.6
Shader model version: No
TV tuner integrated: No
Cooling type: Active
Illumination: Yes
Number of fans: 3
Number of slots: 3
Minimum system power supply: 850
Depth: 140
Height: 61
Length: 330
Weight: 1554
Cables included: Power
Quick installation guide: Yes
Unit Calculated Volume: 0.008707
Product Net Weight: 1.554
Unit Calculated Weight: 1.7
