Description:
- Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors
- 6+1+1 Phase Power Design, Dr.MOS for VCore
- 2 x DDR5 DIMMs
Supports Dual Channel, up to 8200+ (OC) - 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 PCIe 4.0 x1
- Graphics Output Options: 1 HDMI, 1 DisplayPort
- Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
- 1 Blazing M.2 (PCIe Gen5x4)
1 Hyper M.2 (PCIe Gen4x4)
4 SATA3 - 2 USB 3.2 Gen1 Type-C (1 Rear, 1 Front)
5 USB 3.2 Gen1 (3 Rear, 2 Front)
6 USB 2.0 (2 Rear, 4 Front) - Realtek 2.5G LAN
- 802.11axe Wi-Fi 6E + Bluetooth
- Supports BIOS Flashback
Vendor Homepage: www.asrock.com/MB/AMD/B850M-X%20R2.0/index.asp
Category Code: MBA
CnCode: 84733020
Unit Box Height: 0.06
Unit Box Length: 0.3
Unit Box Width: 0.27
M.2: 1
PCI-Express 4.0 16x: 1
PCI-Express 4.0 1x: 1
PCI-Express 5.0 16x: 1
Audio-In: 1
Audio-Out: 1
DisplayPort: 1
HDMI: 1
Microphone: 1
RJ45: 1
USB 2.0: 2
USB 3.2: 3
USB-C: 1
SATA: Yes
SATA 3.0: Yes
USB 2.0: Yes
USB 3.2: Yes
USB-C: Yes
WiFi: Yes
Model: B850M-X WIFI
Chipset: AMD B850
Socket: SAM5
Form Factor: Micro-ATX
Memory type: DDR5
Frequency speed: 8200
Memory slots: 2
Integrated video: Depending on CPU
Integrated audio: Realtek ALC897
Integrated LAN: 2.5 Gigabit
RAID: SATA 0, 1, 10
TPM: Header
Units per Pallet: 0
Units per Shipping Box: 10
Unit Calculated Volume: 0.005702
Product Net Weight: 1.3
Unit Calculated Weight: 1.33
