Description: Intel® B760 (LGA 1700) mATX mortheboard with PCIe 4.0, DDR5, two M.2 slots, Realtek 2.5Gb Ethernet, Wi-Fi 6, DisplayPort, Dual HDMI™, SATA 6 Gbps, rear USB 3.2 Gen 2, front USB 3.2 Gen 1 Type-C®, Aura Sync
– Intel® LGA 1700 Socket: Ready for 13th and 12th Gen Intel® processors
– Ultrafast Connectivity: PCIe 4.0, two M.2 slots, Realtek 2.5Gb Ethernet, Wi-Fi 6, rear USB 3.2 Gen 2, front USB 3.2 Gen 1 Type-C®
– Comprehensive Cooling: VRM heatsinks, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+
– Exclusive Memory Technology: ASUS Enhanced Memory Profile II and ASUS OptiMem II
– Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware
Vendor Homepage: www.asus.com/motherboards-components/motherboards/prime/prime-b760m-a-wifi/
Model: PRIME B760M-A WIFI
Chipset: Intel B760 Express
Socket: LGA1700
Form Factor: Micro-ATX
Memory type: DDR5
Frequency speed: 4800/5000/5200/5400/5600/5800/6000/6200/6400/6600/6800/7000/7200
Memory slots: 4
M.2: 2
PCI-Express 4.0 16x: 3
Audio port: 3
DisplayPort: 1
HDMI: 2
PS/2: 1
RJ45: 1
USB 2.0: 4
USB 3.2: 2
Bluetooth: Yes
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
WiFi: Yes
Integrated video: Depending on CPU
Integrated LAN: 2.5 Gigabit
Integrated audio: Yes
RAID: SATA 0, 1, 5, 10
TPM: Header
Shipping box quantity: 10
Shipping Box Depth: 57.5
Shipping Box Height: 30.5
Shipping Box Weight: 15.93
Shipping Box Width: 37
Unit Brutto Volume: 0.006489
Unit Net Weight: 1
Unit Gross Weight: 1.59
CnCode: 84733020
Unit Box Width: 0.275
Unit Box Length: 0.28
Unit Box Height: 0.07
Full Description Line: Intel B760 Express|LGA1700|Micro-ATX|DDR5|7200/7000/6800/6600/6400/6200/6000/5800/5600/5400/5200/5000/4800 MHz|Memory slots 4|3xPCI-Express 4.0 16x|2xM.2|2xHDMI|1xDisplayPort|4xUSB 2.0|2xUSB 3.2|1xPS/2|1xRJ45|3xAudio port|SATA|USB 2.0|USB 3.2|Bluetooth|WiFi|Video Depending on CPU|LAN 2.5 Gigabit|Audio|RAID SATA 0, 1, 5, 10|TPM Header
Category Code: MBI
