Mainboard GIGABYTE Intel B760 Express LGA1700 Micro-ATX Memory DDR4 Memory slots 4 2xPCI-Express 3.0 1x 1xPCI-Express 4.0 16x 2xM.2 1xHDMI 1xDisplayPort 2xUSB 2.0 1xUSB 3.2 1xUSB-C 1xPS/2 1xOptical S/PDIF 1xRJ45 3xAudio port B760MGPWIFIDDR41.0
119.54 €
Description: B760M GAMING PLUS WIFI DDR4
- Supports Intel® Core™ 14th/ 13th /12th processors
- Unparalleled Performance：Hybrid 4+1+1 Phases Digital VRM Solution
- Dual Channel DDR4：4*DIMMs XMP Memory Module Support
- Next Generation Storage：2*PCIe 4.0 x4 M.2 Connectors
- Fast Networks：Wi-Fi 6 802.11ax, GbE LAN
- Extended Connectivity：Front USB-C® 5Gb/s, DP, HDMI
- Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card
Vendor Homepage: www.gigabyte.com/Motherboard/B760M-GAMING-PLUS-WIFI-DDR4#kf
Model: B760M G P WIFI DDR4
Chipset: Intel B760 Express
Socket: LGA1700
Form Factor: Micro-ATX
Memory type: DDR4
Frequency speed: 2133/2400/2666/2933/3000/3200/3300/3333/3400/3466/3600/3666/3733/3800/3866/4000/4133/4266/4300/4400/4500/4600/4700/4800/4933/5000/5133/5333
Memory slots: 4
M.2: 2
PCI-Express 3.0 1x: 2
PCI-Express 4.0 16x: 1
Audio port: 3
DisplayPort: 1
HDMI: 1
Optical S/PDIF: 1
PS/2: 1
RJ45: 1
USB 2.0: 2
USB 3.2: 1
USB-C: 1
Bluetooth: Yes
PS/2: Yes
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
USB-C: Yes
WiFi: Yes
Integrated video: Depending on CPU
Integrated LAN: Realtek (Gigabit)
Integrated audio: Yes
RAID: SATA 0, 1, 5, 10
TPM: Header
Units per Shipping Box: 10
Shipping Box Depth: 56
Shipping Box Height: 30
Shipping Box Weight: 12.89
Shipping Box Width: 38
Unit Calculated Volume: 0.006384
Product Net Weight: 0.7
Unit Calculated Weight: 1.29
CnCode: 84733020
Category Code: MBI
Full Description Line: Intel B760 Express|LGA1700|Micro-ATX|DDR4|5333/5133/5000/4933/4800/4700/4600/4500/4400/4300/4266/4133/4000/3866/3800/3733/3666/3600/3466/3400/3333/3300/3200/3000/2933/2666/2400/2133 MHz|Memory slots 4|2xPCI-Express 3.0 1x|1xPCI-Express 4.0 16x|2xM.2|1xHDMI|1xDisplayPort|2xUSB 2.0|1xUSB 3.2|1xUSB-C|1xPS/2|1xOptical S/PDIF|1xRJ45|3xAudio port|SATA|USB-C|USB 2.0|USB 3.2|Bluetooth|WiFi|PS/2|Video Depending on CPU|LAN Realtek (Gigabit)|Audio|RAID SATA 0, 1, 5, 10|TPM Header
