Description:
ValueRAM, Kingston’s industry standard memory, delivers award-winning performance and legendary Kingston reliability. When you know what you want, you want ValueRAM.
- Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Dual-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- 16 internal banks; 4 groups of 4 banks each
- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
- Selectable BC4 or BL8 on-the-fly (OTF)
- Fly-by topology
- Terminated control command and address bus
- RoHS Compliant and Halogen-Free
Summary: Kingston Technology ValueRAM . Component for: PC/Server, Internal memory: 16 GB, Memory layout (modules x size): 1 x 16 GB, Internal memory type: DDR4, Memory form factor: 288-pin DIMM, CAS latency: 22, Product colour: Black, Green
Vendor Homepage: https://www.kingston.com/en
Category Code: MEM
CnCode: 84733020
Unit Box Height: 0.008
Unit Box Length: 0.16
Unit Box Width: 0.045
Backlight: No
Buffered memory type: Unregistered (unbuffered)
CAS latency: 22
Component for: PC/Server
Cooling type: Heatsink
ECC: No
Internal memory: 16
Internal memory type: DDR4
JEDEC standard: Yes
Lead plating: Gold
Memory channels: Single-channel
Memory data transfer rate: 3200
Memory form factor: 288-pin DIMM
Memory layout (modules x size): 1 x 16
Memory ranking: 2
Memory voltage: 1.2
Module configuration: 2048M x 64
Product colour: Black/Green
Programming power voltage (VPP): 2.5
Refresh row cycle time: 350
Row active time: 32
Row cycle time: 45.75
Operating temperature (T-T): 0 – 85
Storage temperature (T-T): -55 – 100
Compliance certificates: RoHS
Doesn’t contain: Halogen
Height: 31.25
Width: 133.35
Harmonized System (HS) code: 84733020
Units per Shipping Box: 1
Unit Calculated Volume: 5.76E-05
Unit Calculated Weight: 0.03
