Description: Intel quad-core dual-port 2.5GbE NAS supports M.2 SSD caching and PCIe expandability for high-speed transmission and virtualization applications
Powered by an Intel® Celeron® N5095, quad-core processor (burst up to 2.9GHz), the TS-664 features two 2.5GbE RJ45 ports and Port Trunking for up to 5Gbps combined bandwidth. With M.2 PCIe Gen3 and PCIe Gen 3 slots, the TS-664 provides flexibility in extending NAS functionality, allowing you to install a QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition and various 10GbE/5GbE network cards. The TS-664 comes with 4 GB RAM for running light VMs and Containers, and supports multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable 2.5GbE NAS.
Vendor Homepage: www.qnap.com/en/product/ts-664/specs/hardware
Model: TS-664-4G
NAS features: Ready-to-go
CPU: Intel® Celeron® N5095 (or N5105) 4-core/4-thread processor, burst up to 2.9 GHz
Number of drives/bays: 6
Supported drives: 3.5-inch SATA HDD; 2.5-inch SATA HDD; 2.5-inch SATA SSD
2.5GbE: 2
HDMI: 1
USB 2.0: 2
USB 3.2: 2
Memory: 8
Memory type: DDR4
Flash memory (ROM): 4096
M.2: 2
PCI-E: 1
HDD: Yes
LAN: Yes
Status: Yes
USB: Yes
Power consumption: 44.02
Power supply requirements: 120W adapter, 100-240V
Dimensions: 168 × 235 × 226 mm
Shipping box quantity: 1
Shipping Box Depth: 38
Shipping Box Height: 34.5
Shipping Box Weight: 4.45
Shipping Box Width: 25.5
Unit Brutto Volume: 0.03343
Unit Net Weight: 2.9
Unit Gross Weight: 4.45
CnCode: 84717098
Unit Box Width: 0.255
Unit Box Length: 0.38
Unit Box Height: 0.345
Full Description Line: NAS Ready-to-go|CPU Intel® Celeron® N5095 (or N5105) 4-core/4-thread processor, burst up to 2.9 GHz|Drives/bays 6|2×2.5GbE|1xHDMI|2xUSB 2.0|2xUSB 3.2|Memory 8 GB|DDR4|1xPCI-E|2xM.2|Status|USB|HDD|LAN|Power consumption 44.02 Watts|Power supply requirements 120W adapter, 100-240V
Category Code: STS
