Description: 1/3” 2Megapixel CMOS, 1920×1080 @30FPS FullHD realtime
Minimum illumination: 0.025 lux @ F2.0 (Color, 30 IRE), 0.0025 lux @ F2.0 (B/W, 30 IRE)
True Day/Night (ICR), BLC/ HLC/ DWDR / 3D DNR
Fixed lend 2.8 mm Lens (100°)
Up to 30 meters IR Illumination, Smart IR
H.265+/H.265/H.264+/H.264 encoding, ONVIF (Profile S/Profile T); CGI; P2P; Genetec
Micro SD card (support max. 256 GB)
Wi-Fi IEEE802.11b/g/n 2.4–2.4835 GHz
Dome design, IK10, IP67, -40°C~+60°C, PoE / 12VDC power
Free IP monitoring software available
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Cameras/Wireless-Series/Wi-Fi-Series/2MP/IPC-HDBW1230DE-SW
Model: IPC-HDBW1230DE-SW-0280B
Camera design: Dome
Network Camera Type: Fixed Dome/HDTV/Megapixel/Outdoor
Pixel Resolution: 2
Focal Length: 2.8 mm
IR Illumination: Yes
Sensor size: 1/3”
Lens Mount: M12
Min. Illumination: 0.0025
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
RJ45: 1
Supports card capacities up to: 256GB
Power options: 12V/PoE
Power consumption: 4.9
Environment: Outdoor
Operating temperature range: -40°C~+60°C
Dimensions: Φ110.7 mm × 88.7 mm
Shipping box quantity: 1
Shipping Box Depth: 15
Shipping Box Height: 14.5
Shipping Box Weight: 0.646
Shipping Box Width: 12.5
Unit Brutto Volume: 0.002719
Unit Net Weight: 0.414
Unit Gross Weight: 0.646
CnCode: 85258900
Unit Box Width: 0.125
Unit Box Length: 0.15
Unit Box Height: 0.145
Full Description Line: Type Fixed Dome/HDTV/Megapixel/Outdoor|Pixel Resolution 2 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/3”|Lens Mount M12|Min. Illumination 0.0025 Lux|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xRJ45|Supports card capacities up to 256GB|Power options PoE/12V|Environment Outdoor|Operating temperature range -40°C~+60°C|Dimensions Φ110.7 mm × 88.7 mm
Category Code: FNC
