Description:
> 4-MP 1/1.8" CMOS image sensor, low illuminance, high image definition.
> Outputs max. 4 MP (2688 × 1520) @30 fps.
> Built-in warm light and the max. illumination distance is 30 m.
> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata,IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 G Micro SD card, built-in Mic.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-5-Series/Full-color/IPC-HDW5449TM-SE-LED=S2
Category Code: FNC
CnCode: 85258900
Unit Box Height: 0.13
Unit Box Length: 0.14
Unit Box Width: 0.145
Form factor: Dome
International Protection (IP) code: IP67
Connectivity technology: Wired
Number of effective pixels (H x V): 2688 (H) × 1520 (V)
Optical sensor size: 1/1.8″
Progressive scan: Yes
Sensor type: CMOS
Fixed focus: Yes
Focal length range: 2.8 mm; 3.6 mm
Maximum aperture number: 1
3D NR (Noise Reduction): Yes
Flip & mirror: Yes
Privacy masking: Yes
Total megapixels: 4
Built-in microphone: Yes
Ethernet LAN: Yes
Compatible memory cards: MicroSDHC
Maximum memory card size: 512
Ethernet LAN (RJ-45) ports: 1
Power consumption (Power over Ethernet (PoE)): 9.8
Operating temperature (T-T): –40 °C to +60 °C
Diameter: 122
Weight: 494
Width: 104
Iris: Yes
Lens mount interface: M16
Power requirements: 12 VDC /PoE (802.3af)/ePoE
Units per Shipping Box: 1
Unit Calculated Volume: 0.002639
Unit Calculated Weight: 0.73
