Description:
1/2.7” 5Megapixel progressive CMOS, 2960 × 1668 @ 30FPS max
Minimum illumination: 0.0009 lux @F1.6 (Color, 30 IRE); 0.0005 lux @F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
True Day/Night (ICR), BLC/HLC/True WDR 120 dB/3D DNR
3.6 mm fixed lens (92° HFOV)
Up to 50 meters IR LED Illumination
H.265; H.264; H.264H; H.264B; MJPEG encoding, ONVIF (Profile S/Profile G/Profile T); CGI
Built-in MIC, 1/1 Audio I/O, 1/1 Alarm I/O
Micro SD card up to 256GB supported
Metal case, IP67, -40°C~+60°C, PoE / 12VDC power, 6.8W max
With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, people counting, etc.
Free IP monitoring software available
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-S-Series/5MP/IPC-HFW5541E-ASE=S3
Category Code: FNC
CnCode: 85258900
Unit Box Height: 0.1
Unit Box Length: 0.22
Unit Box Width: 0.11
Audio-In: 1
Audio-Out: 1
RJ45: 1
Alarm In: 1
Alarm Out: 1
Model: IPC-HFW5541E-ASE-0360B-S3
Camera design: Bullet
Network Camera Type: HDTV/Megapixel/Outdoor
Pixel Resolution: 5
Focal Length: 3.6 mm
IR Illumination: Yes
Sensor size: 1/2.7”
Microphone: Built-in
Lens Mount: M12
Min. Illumination: 0
Effective pixels: 2960 (H) × 1668 (V)
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Supports card capacities up to: 256GB
Power options: 12V/PoE
Power supply requirements: PoE / 12VDC power, 6.8W max
Power consumption: 7
Environment: Outdoor
Operating temperature range: -40°C~+60°C
Colour: White
Dimensions: 192.7 mm × 70.5 mm × 66.4 mm
Units per Shipping Box: 1
Unit Calculated Volume: 0
Product Net Weight: 1
Unit Calculated Weight: 1
