Description:
>5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
>Outputs max. 5 MP (2960 × 1668) @25/30 fps.
>Built-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m.
>ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
>Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
>Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions.
>With deep learning algorithm, it supports: AcuPick, video metadata, IVS, face detection, and people counting, etc.
>Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1 TB Micro SD card; built-in Mic
>12 VDC/PoE power supply; ePoE
>IP67 and IK10 protection.
> Field of View: 108.4°
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-5-Series/Smart-Dual-Light/5MP/IPC-HDBW5559R-ASE-IL
Category Code: FNC
CnCode: 85258900
Unit Box Height: 0.135
Unit Box Length: 0.15
Unit Box Width: 0.14
Form factor: Dome
Product colour: White
Adjustment shutter speed: Auto/Manual
Camera shutter speed: 1/3 s–1/100,000 s
Number of effective pixels (H x V): 2960 (H) × 1668 (V)
Optical sensor size: 1/2.7″
Sensor type: CMOS
Fixed focal length: 2.8
Focal length range: 2.8 mm; 3.6 mm; 6 mm
LED type: IR/White
Total megapixels: 5
Built-in microphone: Yes
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 1000
Ethernet LAN (RJ-45) ports: 1
Alarm input channels: 1
Alarm output channels: 1
Operating temperature (T-T): –40 °C to +60 °C
Diameter: 122
Weight: 713
Width: 94
Audio input: 1
Audio output: 1
Lens mount interface: M12
Power source: 12 VDC (±30%); PoE+ (802.3at); ePoE
Model: IPC-HDBW5559R-ASE-IL-0280B
Units per Pallet: 0
Units per Shipping Box: 1
Unit Calculated Volume: 0.002835
Unit Calculated Weight: 0.723
