Description:
360° Coverage with 4-in-1 Cameras
A single fisheye camera can play the role of many, providing a simpler and more competitive security solution. For example, in 4PTZ display mode, it functions as four cameras at once, delivering complete coverage and flexible perspectives.
Multiple Display Modes
Along with the fisheye view, VIGI provides multiple display modes, enabling you to focus on every detail exactly as you prefer.
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
- 5MP Super-High Definition and IR Night Vision
- 360° Coverage without Blind Spots
- Supports Multiple Display Modes△ and ePTZ
- Supports Ceiling Mount / Wall Mount / Pendant Mount§
- Smart Detection
- Smart Video Enhancement Technology
- Built-In Microphone & Speaker
- IP67 Waterproof and IK10 Vandal-Proof
- H.265+ Compression Technology
- Suitable for Small Indoor Areas like Retail Shops and Offices
Summary: TP-Link InSight S655I. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Housing material: Metal. Lens viewing angle, horizontal: 180°, Lens viewing angle, vertical: 180°, Lens viewing angle, diagonal: 180°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7″). Sensor type (panoramic camera): CMOS, Signal-to-Noise Ratio (SNR) (panoramic camera): 52 dB
Vendor Homepage: https://www.tp-link.com/in/business-networking/vigi-network-camera/insight-s655i/
Category Code: FNC
CnCode: 85258900
Unit Box Height: 0.09
Unit Box Length: 0.2
Unit Box Width: 0.17
Housing material: Metal
IK code: IK10
International Protection (IP) code: IP67
Mounting type: Ceiling/wall
Product colour: White
Protection features: Weatherproof
Weatherproof: Yes
Certification: CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF
Connectivity technology: Wired
Day/night mode: Yes
Dynamic range: 120
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Camera shutter speed: 1/3 – 1/10000
Lens viewing angle, diagonal: 180
Lens viewing angle, horizontal: 180
Lens viewing angle, vertical: 180
Minimum illumination: 0
Number of Privacy masking areas: 4
Digital Wide Dynamic Range (DWDR) (panoramic camera): Yes
Optical sensor size: 1/2.7
Progressive scan: Yes
Sensor type: CMOS
Sensor type (panoramic camera): CMOS
Signal-to-Noise Ratio (SNR) (panoramic camera): 52
Detect distance: 28.8
Fixed focal length: 1.44
Identify distance: 2.8
Maximum aperture number: 2
Observe distance: 12
Recognize distance: 5.7
Infra-red wavelength: 850
LED type: IR
Night vision: Yes
Night vision distance: 10
Number of illumination LEDs: 4
Back Light Compensation (BLC): Yes
Bit rate: 64 Kbps to 6 Mbps
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Digital Wide Dynamic Range (DWDR): Yes
Frame rate: 30
Highlight Compensation (HLC): Yes
Image quality adjustment: Brightness/Contrast/Saturation/Sharpness
Maximum resolution: 2560 x 1920
Noise reduction technology: 3D noise reduction
Region of Interest (ROI) encoding: Yes
Smart IR: Yes
Supported graphics resolutions: 1280 x 960/2048 x 1536 (QXGA)/2560 x 1920/320 x 240/640 x 480 (VGA)
Total megapixels: 5
Video compression formats: H.264/H.264+/H.265/H.265+
Video streaming: Yes
Audio system: 2-way
Bit rate range: 0 – 64
Built-in microphone: Yes
Built-in speaker(s): Yes
Number of microphones: 1
Sample rate: 8
Signal-to-Noise Ratio (SNR): 52
Bluetooth: No
Client interoperability: Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Networking standards: IEEE 802.3/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u
Number of simultaneous live view channels: 6
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi: No
Built-in HDD: No
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512
Ethernet LAN (RJ-45) ports: 1
Alert notification type: E-mail,Push notification
Digest authentication: Yes
HTTPS encryption: Yes
IP address filtering: Yes
Motion sensor: Yes
Password protection: Yes
Privacy protection: Yes
Video motion detection: Yes
Cloud-managed: Yes
Reset button: Yes
Web browser: Yes
DC output voltage: 12
Power consumption (max): 11.76
Power consumption (Power over Ethernet (PoE)): 12.14
Power source type: DC,PoE
Operating relative humidity (H-H): 0 – 95
Operating temperature (T-T): -30 – 60
Storage relative humidity (H-H): 0 – 95
Storage temperature (T-T): -40 – 60
Diameter: 132
Height: 56
Weight: 440
Number of cameras: 1
Lens mount interface: M12
Model: InSight S655I
Units per Pallet: 0
Units per Shipping Box: 1
Unit Calculated Volume: 0.00306
Unit Calculated Weight: 0.755
