Description:
> 1/2.7" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 6 MP (3288 × 1850)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in multi-core light, the max. IR distance is 60 m and the max. warm light distance is 60 m.
> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human), stay detection, loitering detection, face detection (full image).
> Abnormality detection: Motion detection,video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply.
> IP67, IK10 (optional, IEC 62262:2002) protection.
> SMD 4.0.
> Supports AI SSA.
> SMD area can be set in warm light areas that support triggering alarms.
> Focal Length 2.7 mm-13.5 mm. Field of View 114°–32°
Vendor Homepage: hwww.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-3-Series/Smart-Dual-Light/IPC-HFW3649T-ZAS-IL
Category Code: FNC
CnCode: 85258900
Form factor: Bullet
Product colour: Black
Connectivity technology: Wired
Camera shutter speed: Auto/Manual 1/3 s–1/100,000 s
Camera shutter type: Electronic/Mechanical
Minimum illumination: 0.0005
Effective sensor resolution: 6
Optical sensor size: 1/2.7″
Progressive scan: Yes
Sensor type: CMOS
Focal length range: 2.7 mm-13.5 mm
Audio input channels: 1.0
Audio output channels: 1.0
Built-in microphone: Yes
Ethernet LAN (RJ-45) ports: 1
Alarm input channels: 1
Alarm output channels: 1
DC output voltage: 12
Power consumption (max): 9.9
Power consumption (Power over Ethernet (PoE)): 12.5
Power consumption (typical): 3.8
Power source type: DC,PoE
Operating temperature (T-T): –30 °C to +60 °C
Depth: 90.7
Length: 238.5
Weight: 835
Width: 90.7
Lens mount interface: M14
Unit Calculated Volume: 0.004675
Unit Calculated Weight: 1.09
