Description: > 6-MP 1/2.5″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 6 MP (2560 × 2560)@25/30 fps.
> 360° fisheye monitoring covers all the corners without any blind zone.
> Supports fisheye front-dewarp and back-dewarp.
> Supports split screen for 2 and 4 windows.
> Built-in IR LED, and the max. illumination distance is 15 m.
> ROI, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: Perimeter Protection, People Counting, Heat map.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1TB Micro SD card;
> Built-in speaker and dual Mic. Supports two-way talk.
> 12 VDC/ PoE(802.3af) power supply.
> IP67 and IK10 protection.
> Focal Length 1.68 mm, Field of View 185*185°
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-Panoramic-Series/Fisheye-Series/IPC-EBW5641-AS
Model: IPC-EBW5641-AS
Camera design: Other
Network Camera Type: HDTV/Megapixel
Pixel Resolution: 6
Focal Length: 1.68 mm
IR Illumination: Yes
Sensor size: 1/2.5″ CMOS
Microphone: Built-in
Lens Mount: M12
Min. Illumination: 0.0006
Effective pixels: 2560 (H) × 2560 (V)
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Alarm In: 1
Alarm Out: 1
Audio-In: 1
Audio-Out: 1
RJ45: 1
Supports card capacities up to: 512GB
Power options: PoE
Power supply requirements: 12 VDC, 1 A; PoE (802.3af)
Power consumption: 10.1
Environment: Outdoor
Operating temperature range: –30 °C to +60 °C
Colour: White
Dimensions: Φ122 mm × 53.3 mm
Units per Shipping Box: 1
Shipping Box Depth: 16
Shipping Box Height: 16
Shipping Box Weight: 0.77
Shipping Box Width: 11
Unit Calculated Volume: 0.002816
Product Net Weight: 0.46
Unit Calculated Weight: 0.77
CnCode: 85258900
Unit Box Width: 0.11
Unit Box Length: 0.16
Unit Box Height: 0.16
Full Description Line: Type HDTV/Megapixel|Pixel Resolution 6 Mega Pixel|Focal Length 1.68 mm|IR Illumination|Sensor size 1/2.5″ CMOS|Microphone Built-in|Lens Mount M12|Min. Illumination 0.0006 Lux|Effective pixels 2560 (H) × 2560 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 512GB|Power options PoE|Power supply requirements 12 VDC, 1 A; PoE (802.3af)|Environment Outdoor|Operating temperature range –30 °C to +60 °C|Colour White|Dimensions Φ122 mm × 53.3 mm
Category Code: FNC
