Description: 1/2.8”2 x 4 Megapixel progressive CMOS, 4096 × 1800
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Sensitivity: 0.0005 lux @ F1.0, 0.0002 lux @ F1.0 (B/W,30 IRE), 0 Lux (Illuminator on)
Fixed focus lens 3.6 mm (x 2), Field if view: 180°
Illumination Distance 40m, warm white LED
Video Frame Rate: 4096 × 1800 @ (1–25 fps)
BLC / HLC / True WDR 140dB / 3D DNR
1/1 Audio I/O, 1/1 Alarm I/O, Built-in MIC, Built-in Speaker
256 GB SD card supprt, ONVIF (Profile S/Profile G/Profile T); CGI; Milestone
Smart capabilities: Abandoned object; missing object, Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection, Tripwire people counting and people counting in area, generating and exporting report (day/month/year); queue management, generating and exporting report (day/month); 4 rules can be set for tripwire, people counting in area and queue management, Heat Map
Power: 12V DC 13.8W, PoE
Metal case, IP67, −40°C to +60°C
Wall bracket included
Known aliases: DH-IPC-PFW5849P-A180-E2-ASTE-0360B, IPC-PFW5849P-A180-E2-ASTE-0360B, DH-IPC-PFW5849-A180-E2-ASTE-0360B, IPC-PFW5849-A180-E2-ASTE-0360B, IPC-PFW5849P-A180-E2-ASTE
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-Series/Panoramic-Series/Multi-Sensor/IPC-PFW8840-A180
Camera design: Box
Network Camera Type: Fixed/Outdoor
Pixel Resolution: 4
Focal Length: 3.6mm
IR Illumination: Yes
Sensor size: 1/2.8”4 × 2Megapixel progressive CMOS
Microphone: Built-in
Lens Mount: M12
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Alarm In: 1
Alarm Out: 1
Audio-In: 1
Audio-Out: 1
RJ45: 1
SD Card Slot: 1
Supports card capacities up to: 256GB
Power options: 12V/PoE
Power supply requirements: 12V DC 13.8W, PoE
Environment: Outdoor
Operating temperature range: −40°C to +60°C
Dimensions: 298.3 mm × 172.5 mm × 120.5 mm
Shipping box quantity: 1
Shipping Box Depth: 36.5
Shipping Box Height: 18
Shipping Box Weight: 1.84
Shipping Box Width: 17.5
Unit Brutto Volume: 0.0115
Unit Net Weight: 1.42
Unit Gross Weight: 1.84
CnCode: 85258900
Unit Box Width: 0.175
Unit Box Length: 0.365
Unit Box Height: 0.18
Full Description Line: Type Fixed/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 3.6mm|IR Illumination|Sensor size 1/2.8”4 × 2Megapixel progressive CMOS|Microphone Built-in|Lens Mount M12|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xSD Card Slot|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements 12V DC 13.8W, PoE|Environment Outdoor|Operating temperature range −40°C to +60°C|Dimensions 298.3 mm × 172.5 mm × 120.5 mm
Category Code: FNC
