Description: NVR5216-XI
16CH 1U 2HDDs WizMind Network Video Recorder
> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
> Max. decoding capability: 32 × 1080p@30 fps
> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 32 MP.
> Supports AcuPick with up to 16 channels.
> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 16-channel perimeter protection; 16-channel SMD Plus.
> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
> Supports N+M cluster, ISCSI.
> Supports EPTZ, and one-click arming and disarming.
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Recorders/WizMind-Series/NVR5-XI/2HDD/NVR5216-XI
CnCode: 85219000
Unit Box Width: 0.135
Unit Box Length: 0.435
Unit Box Height: 0.36
Category Code: NVR
Model: NVR5216-XI
Number of Channels: 16
Desktop/pedestal: Yes
Rack: Yes
SATA: Yes
15pin D-sub: 1
Alarm In: 1
Alarm Out: 1
Audio-In: 1
Audio-Out: 1
HDMI: 1
RS232: 1
RS-485: 1
USB 2.0: 1
USB 3.0: 1
Power supply requirements: 12 VDC, 4 A
Dimensions: 375.0 × 282.9 x 56.0 mm
Colour: Black
Units per Shipping Box: 1
Shipping Box Depth: 43.5
Shipping Box Height: 36
Shipping Box Weight: 2.84
Shipping Box Width: 13.5
Unit Calculated Volume: 0.02114
Product Net Weight: 1.56
Unit Calculated Weight: 2.84
Full Description Line: Channels 16|Desktop/pedestal|Rack|SATA|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|1xRS232|1xUSB 2.0|1xUSB 3.0|1xRS-485|1xAlarm In|1xAlarm Out|Power supply requirements 12 VDC, 4 A|Dim. 375.0 × 282.9 x 56.0 mm|Colour Black
