Description:
The ASUS Prime AP303 is a compact 44-liter ATX case with support for graphics cards up to 360mm long, 360mm radiators up to 60mm thick, and ATX PSUs up to 180mm long.
ASUS Prime AP303 – Mesh Panel
Compact Frame. Massive Potential.
The ASUS Prime AP303 is a compact 44-liter ATX chassis that accommodates 360mm radiators up to 60mm thick and graphics cards up to 360mm long. It features a graphics card bracket and holder to keep cards firmly mounted, plus an internal power cable that delivers 15 amperes to maintain stable power delivery for high-end PC builds.
- Compact Size with Maximal Capacity: 44-liter footprint supports up to 360mm graphics cards, up to 360mm radiators (60mm max thickness), up to 180mm ATX PSUs
- Enhanced Rigidity for Graphics Cards: Added bracket supports GeForce RTX™ 50 Series graphics cards from 310mm to 360mm long, reducing sagging and movement
- Power Cable for High-End Systems: UL-certified power cable delivers 15 amps to ensure stable operation
- Optimized for Cooling: Support for up to 360mm radiators and up to seven fans handles any thermal scenario
- Front Panel USB Type-C® Support: A 20Gbps USB Type-C port enables high-speed data transfer speeds
Summary: ASUS PRIME AP303 MESH BLACK. Form factor: Midi Tower, Type: PC, Product colour: Black. Rear fans installed: 1x 120 mm, Rear fans diameters supported: 120 mm, Top fans diameters supported: 120,140 mm. Supported HDD sizes: 2.5,3.5". Width: 215 mm, Depth: 485 mm, Height: 425 mm
Vendor Homepage: https://www.asus.com/motherboards-components/cases/prime/asus-prime-ap303-mesh-panel/
Category Code: CAS
CnCode: 84733080
Anti-dust filter: Yes
Cable management: Yes
Form factor: Midi Tower
Illumination: No
Maximum CPU cooler height: 165
Maximum graphics card length: 360
Maximum PSU length: 180
Number of 2.5″ bays: 2
Number of 3.5″ bays: 1
Number of expansion slots: 7
Number of internal 3.5″ bays: 1
Product colour: Black
Side window: No
Suitable for: Gaming
Supported motherboard form factors: ATX/micro ATX/Mini-ITX
Type: PC
Combo headphone/mic port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2×2 Type-C ports quantity: 1
Front radiator installed: No
Number of rear fans supported (max): 1
Number of top fans supported (max): 3
Rear fans diameters supported: 120
Rear fans installed: 1x 120 mm
Rear radiator installed: No
Rear radiator sizes supported: 120
Top fans diameters supported: 120/140
Top radiator installed: No
Top radiator sizes supported: 120/140/240/280/360
Supported HDD sizes: 2.5/3.5
Depth: 485
Height: 425
Weight: 6800
Width: 215
Model name: PRIME AP303 MESH BLACK
Unit Calculated Volume: 0.07989
Unit Calculated Weight: 8.1
