Mainboard MSI Intel B760 Express LGA1700 Micro-ATX Memory DDR4 Memory slots 4 2xPCI-Express 1x 1xPCI-Express 16x 2xM.2 1x15pin D-sub 1xHDMI 1xDisplayPort 4xUSB 2.0 1xUSB 3.2 1xUSB-C 2xPS/2 1xRJ45 3xAudio port PROB760M-PDDR4

Description: – Supports 12th/13th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
– Supports DDR4 Memory, Dual Channel DDR4 4800+MHz (OC)
– Core Boost : With premium layout and digital power design to support more cores and provide better performance
– Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
– Lightning Fast Experience: PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
– AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
– Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength
Vendor Homepage: www.msi.com/Motherboard/PRO-B760M-P-DDR4
Model: PRO B760M-P DDR4
Chipset: Intel B760 Express
Socket: LGA1700
Form Factor: Micro-ATX
Memory type: DDR4
Frequency speed: 2133/2400/2666/2933/3200/3333/3400/3466/3600/3733/3800/4000/4200/4266/4400/4600/4800
Memory slots: 4
M.2: 2
PCI-Express 16x: 1
PCI-Express 1x: 2
15pin D-sub: 1
Audio port: 3
DisplayPort: 1
HDMI: 1
PS/2: 2
RJ45: 1
USB 2.0: 4
USB 3.2: 1
USB-C: 1
SATA: Yes
USB 2.0: Yes
USB 3.2: Yes
Integrated video: Depending on CPU
Integrated LAN: Realtek RTL8111H (Gigabit)
Integrated audio: Realtek ALC897
RAID: SATA 0, 1, 5, 10
TPM: Header
Shipping box quantity: 1
Shipping Box Depth: 30
Shipping Box Height: 5.5
Shipping Box Weight: 0.87
Shipping Box Width: 27.5
Unit Brutto Volume: 0.004537
Unit Net Weight: 0.72
Unit Gross Weight: 0.87
CnCode: 84733020
Unit Box Width: 0.275
Unit Box Length: 0.3
Unit Box Height: 0.055
Full Description Line: Intel B760 Express|LGA1700|Micro-ATX|DDR4|4800/4600/4400/4266/4200/4000/3800/3733/3600/3466/3400/3333/3200/2933/2666/2400/2133 MHz|Memory slots 4|2xPCI-Express 1x|1xPCI-Express 16x|2xM.2|1x15pin D-sub|1xHDMI|1xDisplayPort|4xUSB 2.0|1xUSB 3.2|1xUSB-C|2xPS/2|1xRJ45|3xAudio port|SATA|USB 2.0|USB 3.2|Video Depending on CPU|LAN Realtek RTL8111H (Gigabit)|Audio Realtek ALC897|RAID SATA 0, 1, 5, 10|TPM Header
Category Code: MBI
