Performance C Series
The new Xilence Performance C series is focusing on the essentials. Designed for office and home computers, the new Performance C series delivers stable voltages with high efficiency (ErP2014). This guarantees a considerably low fan noise. Four built-in safety circuits ensure safe operation at all times.
- extremely silent cooling: large 120mm fan
- excellent air flow design for a better heat dissipation
- following safety design:
- Over Voltage Protection (OVP)
- Under Voltage Protection (UVP)
- Short Circuit Protection (SCP)
- Over Load Protection (OLP)
- low stand-by consumption
- complies with ErP2014 norm
Xilence Performance C XP600R6. Total power: 450 W, AC input voltage: 110 - 240 V, Peak power: 600 W. Motherboard power connector: 20+4 pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Package width: 230 mm, Package depth: 165 mm, Package height: 100 mm
Specifikacijos
| Vendor Homepage | https://www.xilence.de/en/products/power-supplies/performance-c-series/performance-c-series.html |
|---|---|
| Category Code | PSU |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.23 |
| Unit Box Width | 0.17 |
| AC input frequency | 50 Hz |
| AC input voltage | 110 - 240 V |
| Max output current (+12V) | 18 A |
| Max output current (+12V2) | 20 A |
| Max output current (+3.3V) | 15 A |
| Max output current (+5V) | 15 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Peak power | 600 W |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over voltage/Overload/Short circuit/Under voltage |
| Total power | 450 W |
| Cabling type | Non-Modular |
| CPU power connector (4+4 pin) | Yes |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| PCI Express power connectors (6+2 pin) | 1 |
| ATX version | 2.31 |
| Power supply unit (PSU) form factor | ATX |
| Purpose | PC |
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| Product colour | Black |
| Package depth | 165 mm |
| Package height | 100 mm |
| Package type | Box |
| Package weight | 1630 g |
| Package width | 230 mm |
| Harmonized System (HS) code | 84733020 |
| Model name | XP600R6 |
| Units per Pallet | 144 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.00391 cubm |
| Unit Calculated Weight | 1.66 kg |
