Description:
TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like static
routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The IP-MAC-Port
Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-ofService (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ managed Switches provide a reliable, secure solution for enterprise, campus and ISP networks.
- 24× Gigabit 802.3af/at PoE+ ports and 4× Gigabit SFP slots
- 384 W total PoE budget with up to 30 W PoE output per port
- Centralized cloud management via the web or the Omada app
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
- ERPS supports rapid protection and recovery in a ring topology
- Durable metal casing and rack-mountable design
Summary: TP-Link Omada 28-Port Gigabit L2+ Managed Switch with 24-Port PoE+. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45/Micro-USB. MAC address table: 16000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Vendor Homepage: https://www.tp-link.com/en/business-networking/omada-switch-poe/sg3428mp/#overview
Category Code: SWI
CnCode: 85176200
Unit Box Height: 0.1
Unit Box Length: 0.53
Unit Box Width: 0.44
ARP inspection: Yes
Cloud-managed: Yes
Configuring Location Settings (CLI): Yes
Quality of Service (QoS) support: Yes
Switch layer: L2+
Switch type: Managed
System event log: Yes
Web-based management: Yes
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Console port: RJ-45/micro-USB
Gigabit Ethernet (copper) ports quantity: 24
Power connector: AC-in jack
SFP module slots quantity: 4
10G support: No
Active link detection: Yes
Broadcast storm control: Yes
Copper ethernet cabling technology: 1000BASE-T/10BASE-T
Ethernet LAN data rates: 10,100,1000
Flow control support: Yes
Head-of-line (HOL) blocking: Yes
IP routing: Yes
Link aggregation: Yes
Networking standards: IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3z
Number of VLANs: 4000
Port mirroring: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
Virtual LAN features: MAC address-based VLAN/Port-based VLAN/Private VLAN/Tagged VLAN/Voice VLAN
VLAN support: Yes
Forwarding rate: 41.66
Jumbo frames: 9000
Jumbo frames support: Yes
MAC address table: 16000
Packet buffer memory: 12
Store-and-forward: Yes
Switching capacity: 56
Access Control List (ACL): Yes
Authentication: MAC-based authentication,Port-based authentication
BPDU filtering/protection: Yes
DHCP features: DHCP client/DHCP relay/DHCP server/DHCP snooping/DHCPv6 client/DHCPv6 snooping
IGMP snooping: Yes
IP-MAC-Port binding: Yes
Loop protection: Yes
MAC address filtering: Yes
Security algorithms: SSH/SSL/TLS
SSH/SSL support: Yes
Static port security: Yes
Multicast support: Yes
GARP VLAN Registration Protocol (GVRP): Yes
Management protocols: SNMPv1/v2c/v3, LLDP/LLDP-MED
Form factor: 1U
LED indicators: Yes
Number of fans: 2
Product colour: Black
Rack mounting: Yes
Export Control Classification Number (ECCN): EAR99
AC input frequency: 50/60
AC input voltage: 100 – 240
Power consumption (max): 480.1
Power source: AC
Power supply included: Yes
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30
Power over Ethernet plus (PoE+) ports quantity: 24
Total Power over Ethernet (PoE) budget: 384
Heat dissipation: 1637.14
Operating relative humidity (H-H): 10 – 90
Operating temperature (T-T): 0 – 45
Storage relative humidity (H-H): 5 – 90
Storage temperature (T-T): -40 – 70
Depth: 330
Height: 44
Width: 440
Quick start guide: Yes
User guide: Yes
Certification: CE, FCC, RoHS
Series: Omada
Model name: TL-SG3428MP
Units per Shipping Box: 4
Unit Calculated Volume: 0.0288
Unit Calculated Weight: 6.59
