Description:
The Club 3D Ultra High Speed HDMI™2.1 Cable is built to handle the highest
quality video- and audio- signals.
HDMI™2.1 Increased Bandwidth to 48Gbps.
The increase in maximum bandwidth compared to previous versions is
achieved by increasing both the bitrate of the data channels (from 6Gbps
to 12Gbps) and the number of channels (from 3 to 4). This allows support
for resolutions up to supports 4K at 120Hz! New feature included in this
Specification is Display Stream Compression (DSC) 1.2 , this is used for video
formats higher than 8K with 4:2:0.
Enhanced refresh rate features:
- Variable Refresh Rate (VRR) reduces or eliminates lag, stutter and frame
tearing for more fluid motion in games
- Quick Media Switching (QMS) for movies and video eliminates the delay that
can result in blank screens before content is displayed
- Quick Frame Transport (QFT) reduces latency.
- HDMI™2.1 also supports Static- and Dynamic HDR metadata.
All HDMI™2.1 features are fully supported by this Club3D CAC-1374 Cable. It is
the ideal solution for the ultimate future proof HDMI™2.1 experience.
- Features:
- Fully Compliant to the Ultra High Speed HDMI™2.1 specification
- Professional quality cable
- Low EMI emission
- Gold plated connectors for maximum conductivity and 26 AWG
- Enhanced gaming and media features
- Color space BT.2020 with 10bits,12bits,16bits
- Backwards compatible to earlier HDMI™ versions
- Supports Display Stream Compression (DSC) 1.2
- Supports (U)HD resolutions up to 4K120Hz (with DSC 1.2) or 8K60Hz
- Supports Enhanced Audio Return Channel (eARC)
- Supports Static- and Dynamic- HDR Metadata
- Support for VRR, QMS, QFT and Auto Low Latency Mode
Specifikacijos
| Quantity | 5 |
|---|---|
| Vendor Homepage | www.club-3d.com/en/detail/2533/ultra_high_speed_hdmi_4k120hz_8k60hz_cable_48gbps_m-m_4_m-13.12ft_26awg/ |
| Category Code | VCB |
| Unit Box Height | 0.175 |
| Unit Box Length | 0.175 |
| Unit Box Width | 0.06 |
| 3D | Yes |
| Audio Return Channel (ARC) | Yes |
| AWG wire size | 26 |
| Cable length | 4 m |
| Cable type | Round cable |
| Connector 1 | HDMI Type A (Standard) |
| Connector 1 form factor | Straight |
| Connector 1 gender | Male |
| Connector 2 | HDMI Type A (Standard) |
| Connector 2 form factor | Straight |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Data transfer rate | 48 Gbit/s |
| Enhanced Audio Return Channel (eARC) | Yes |
| HDMI cable type | Ultra High Speed HDMI cable |
| HDMI version | 2.1 |
| High Dynamic Range (HDR) supported | Yes |
| Maximum refresh rate | 120 Hz |
| Plug and Play | Yes |
| Product colour | Black |
| Supported graphics resolutions | 3840 x 2160/7680 x 4320 |
| Supported video modes | 2160p/4320p |
| Certification | Meets ROHS, FCC, and CE EMI requirements |
| Weight | 322 g |
| Package depth | 175 mm |
| Package height | 60 mm |
| Package type | Box |
| Package weight | 400 g |
| Package width | 175 mm |
| Quantity per pack | 1 pc(s) |
| Paper/cardboard packaging weight | 70 g |
| Plastic packaging weight | 8 g |
| Total paper/cardboard packaging weight | 0 g |
| Total plastic packaging weight | 0 g |
| Harmonized System (HS) code | 8544 4290 |
| Model | CAC-1374 |
| Units per Pallet | 0 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.001837 cubm |
| Unit Calculated Weight | 0.42 kg |
