MSI’s mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components.
To fulfill the desire for showcasing an ARGB PC build, the MAG PANO 110R Series features a 270-degree panoramic display, enhancing aesthetics and maintaining a clean design.
Decorated with a metal nameplate to highlight the MAG family identity.
Featuring a 1-to-5 ARGB fan control hub, this system is fully compatible with MSI Mystic Light, allowing for easy sync and customizable ARGB lighting effects.
Pre-installed with 3 x ARGB reverse blade fans at the side and 1 x ARGB fan at the rear for optimal airflow and a clean, stylish design.
- 270-Degree Display: The chassis features a 270-degree panoramic design with tempered glass, providing an expansive view to showcase detailed components
- Measurements: Supports multiple motherboard sizes, including regular ATX, Micro-ATX, Mini-ITX and back-connect ATX and Micro-ATX, allowing users to customize their PC setup
- Pre-build with Reverse Blades Fan: Pre-installed reverse blade fans on the side ensure an unobstructed display of the ARGB fan’s lighting effects, free from interference by fan frames
- ARGB-Fan Control Board: The 1-to-5 ARGB fan control board supports up to 5 ARGB fans, allowing users to adjust 18 ARGB lighting effects with a single LED switch button
- Upgrade Airflow Layout: Supports up to 10 fans, a 360mm radiator on top and a 120mm radiator at rear. The lower chamber, surrounded by vents, further enhances heat dissipation for optimal performance
| Summary | MSI MAG PANO 110R PZ. Form factor: Midi Tower, Type: PC, Product colour: Black. Power supply location: Bottom, Supported power supply form factors: ATX. Side fans installed: 3x 120 mm, Side fans diameters supported: 120,140 mm, Rear fans installed: 1x 120 mm. Supported HDD sizes: 2.5,3.5". Width: 225 mm, Depth: 420 mm, Height: 485 mm |
|---|---|
| Vendor Homepage | https://www.msi.com/PC-Case/MAG-PANO-110R-PZ/Overview |
| Category Code | CAS |
| Unit Box Height | 0.535 |
| Unit Box Length | 0.57 |
| Unit Box Width | 0.33 |
| Form factor | Midi Tower |
| Illumination location | Case fans |
| LED indicators | Yes |
| Material | Tempered glass |
| Maximum CPU cooler height | 160 mm |
| Maximum graphics card length | 200 mm |
| Maximum PSU length | 400 mm |
| Number of 2.5" bays | 2 |
| Number of 3.5" bays | 2 |
| Number of expansion slots | 7 |
| On/off button | Yes |
| Product colour | Black |
| Side window | Yes |
| Suitable for | Gaming |
| Supported motherboard form factors | ATX/micro ATX/Mini-ATX |
| Type | PC |
| Power supply included | No |
| Power supply location | Bottom |
| Supported power supply form factors | ATX |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Bottom fans diameters supported | 120/140/160 mm |
| Bottom radiator sizes supported | 120/240/360 mm |
| Number of bottom fans supported (max) | 3 |
| Number of rear fans supported (max) | 1 |
| Number of side fans supported (max) | 3 |
| Number of top fans supported (max) | 3 |
| Rear fans diameters supported | 120 mm |
| Rear fans installed | 1x 120 mm |
| Rear radiator sizes supported | 120 mm |
| Side fans diameters supported | 120/140 mm |
| Side fans installed | 3x 120 mm |
| Side radiator sizes supported | 120/240/360 mm |
| Top fans diameters supported | 120/140 mm |
| Top radiator sizes supported | 120/240/360 mm |
| Supported HDD sizes | 2.5/3.5 " |
| Depth | 420 mm |
| Height | 485 mm |
| Width | 225 mm |
| Model name | MAG PANO 110R PZ |
| Case product features | Transparent panel |
| Units per Pallet | 0 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.09086/0.1006 cubm |
| Unit Calculated Weight | 11.3 kg |
