High Performance RGB Fan
Pushing air through the radiator effectively while maintaining the stunning looks of RGB fans.
IMPROVED DESIGNS, IMPROVED PERFORMANCE
Compared to the Galahad AIO, the Galahad ll Trinity series shows significant improvement in cooling performance thanks to the many design changes that were introduced.
CHOOSE PREFERABLE LOOK
The Galahad II Trinity series’ pump cap has three interchangeable designs, each with a unique look and two rings of colors that can be individually controlled with different lighting effects.
HIGH DENSITY ALUMINUM RADIATOR
This 27mm thick radiator features single-wave radiator fins with 20 FPI (fins per inch), which is less airflow restrictive and can result in greater thermal performance.
DAISY-CHAINABLE ARGB FAN
The ARGB PWM fans can be daisy-chained by a single short cable which can be hidden inside the frame of the fan. The 120mm fan is 25mm thick and is equipped with fluid dynamic bearings for stable and quiet operations while effectively providing airflow to the radiator.
MOUNT IN ANY WAY
This innovative 45° tubing connector gives the tubes the freedom of 360° rotation, allowing the Galahad ll Trinity series to be installed in many different ways.
INSTALATION MADE EASY, FOR YOU
The Galahad II Trinity series introduces redesigned mounting backplates to provide a hassle-free installation to users while maintaining compatibility with most mainstream CPU sockets. The backplates have a one-piece design with fixed struts to make installation easier.
It also comes with a thermal paste control film and spreader to help ensure the right amount of thermal paste is applied for effective heat dissipation.
SEAMLESS SOFTWARE
Control and preview with precision the lighting effect and real-time motor speed of the Galahad II Trinity Pump and fans with the L-Connect 3.
SIMPLE CONNECTION
The controller is built into the pump and the fan can be connected to the pump to control via L-Connect 3.
- 3 interchangeable pump looks that can be customized with L-Connect 3
- Factory installed with ARGB daisy-chainable radiator fans or UNI FAN SL-INF
- Pump motor speed goes up to 3200RPM
- Includes a newly designed copper plate and creates straightened Liquid coolant pathway
- 45-degree tubing connector with tubes’ inner diameter increased to 7mm
Specifikacijos
| Vendor Homepage | https://lian-li.com/product/galahad-ii-trinity/ |
|---|---|
| Category Code | COC |
| Unit Box Height | 0.15 |
| Unit Box Length | 0.31 |
| Unit Box Width | 0.235 |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Fan diameter | 120 mm |
| Fan noise level (max) | 35.4 dB |
| Fan speed (max) | 2450 RPM |
| Maximum air pressure | 3.66 mmH2O |
| Maximum airflow | 89.1 cfm |
| Pump motor speed | 3200 RPM |
| Pump noise level | 16.59 dB |
| Quantity per pack | 1 pc(s) |
| Suitable location | Computer case |
| Supported processor sockets | Socket AM4/Socket AM5 |
| Type | All-in-one liquid cooler |
| Number of fans | 2 fan(s) |
| Number of fins | 1 |
| Product colour | Black |
| Radiator material | Aluminum |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Pump depth | 74 mm |
| Pump height | 69 mm |
| Pump width | 74 mm |
| Radiator depth | 119.2 mm |
| Radiator height | 27 mm |
| Radiator width | 277.5 mm |
| Tube length | 385 mm |
| Cables included | 4-pin,SATA |
| CPU bracket(s) | Yes |
| Mounting kit | Yes |
| RGB controller included | Yes |
| Screws included | Yes |
| Model | G89.GA2T24W.00 |
| Model name | GA II Trinity 240, GA2T24W WHITE |
| Units per Shipping Box | 6 |
| Unit Calculated Volume | 0.01294 cubm |
| Unit Calculated Weight | 2.44 kg |
