The Lite Series is a great choice for consumers looking for high-quality monitoring products at a reasonable price. Its low cost and high performance make it ideal for residential areas and SMB solutions. This series is equipped with a wide range of technologies, such as full-color and starlight, providing various solutions for different scenarios.
Two-way Talk
With its built-in high-sensitivity microphone and high-power speaker, the camera enables two-way communication through the mobile app.
Smart Dual Light
With its smart dual-light mechanism, the camera automatically turns on the white light when the Perimeter Protection/SMD Plus function of AI XVR detects a target in the rule area to capture clear, vivid images. When the target leaves the rule area, the camera automatically switches from white light to IR light to significantly reduce light pollution.
Smart Light+
Equipped with advanced LEDs and beam processing technology, the camera effectively reduces interference from stray light, ensuring concentrated illumination within the lens’s field of view. This allows it to produce clear images that reveal fine details even in low-light conditions.
Advanced 3DNR
Dahua’s advanced 3DNR technology reduces image noise with little to no impact on image sharpness, especially in poor lighting conditions. It detects noise and compares sequential frames to effectively reduce it. It also makes efficient use of bandwidth, saving storage space.
Protection
IP67: The camera passed a series of rigorous dust and immersion tests. Its enclosure is both dust-proof and waterproof and can function normally while being immersed in water up to 1 m deep for up to 30 minutes.
4 Signals over 1 Coaxial Cable
HDCVI technology supports four signals (video, audio*, data, and power) that are simultaneously transmitted over a coaxial cable. Dual-way data transmission allows the HDCVI camera to interact with the XVR to perform various actions, such as sending control signals and triggering alarms. HDCVI technology also supports PoC, making the camera easy and quick to install.
*Audio input is available for select HDCVI camera models.
Super Adapt
With its intelligent algorithm, the camera automatically adjusts its parameters to provide optimal performance and vivid images.
- The parameters and datasheets below can only be applied to1500-IL-T series
- Max. 25 fps@5MP
- Two-way Talk
- Smart Light+
- Smart Dual Light
- 30 m illumination distance
- 3DNR
- 3.6 mm fixed lens (2.8 mm optional)
- CVI/CVBS/AHD/TVI switchable
- IP67, 12 VDC
Specifikacijos
| Vendor Homepage | https://www.dahuasecurity.com/ceen/products/All-Products/HDCVI-Cameras/Lite-Series/5MP/Two-way-Talk/HAC-HFW1500RL-IL-T |
|---|---|
| Category Code | HSC |
| Unit Box Height | 0.079 |
| Unit Box Length | 0.174 |
| Unit Box Width | 0.081 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Remote viewing | Yes |
| Built-in light | Yes |
| Certification | CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035; |
| Form factor | Bullet |
| Mounting type | Ceiling/wall |
| Product colour | White |
| Housing material | Plastic |
| International Protection (IP) code | IP67 |
| Minimum illumination | 0.01 lx |
| Angle of rotation | 360 ° |
| Lens viewing angle, horizontal | 113.3 ° |
| Lens viewing angle, vertical | 62.1 ° |
| Lens viewing angle, diagonal | 134.3 ° |
| Tilt angle range | 0 - 90 ° |
| Pan range | 0 - 360 ° |
| White balance | Area white balance/Auto |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/100000 s |
| Number of Privacy masking areas | 8 |
| Number of sensors | 1 |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Number of lenses | 1 |
| Detect distance | 59.8 m |
| Observe distance | 23.9 m |
| Recognize distance | 12 m |
| Fixed focus | Yes |
| Focus | Motorized/Manual |
| Identify distance | 6 m |
| Maximum aperture number | 1.6 |
| Fixed focal length | 2.8 mm |
| Night vision | Yes |
| Night vision distance | 30 m |
| Number of illumination LEDs | 2 |
| Maximum resolution | 2880 x 1620 pixels |
| Total megapixels | 5 MP |
| Supported graphics resolutions | 1920 x 1080 (HD 1080)/960 x 480/960 x 576 |
| Frame rate | 30 fps |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Gain control type | Auto/Manual |
| Back Light Compensation (BLC) | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Highlight Compensation (HLC) | Yes |
| Smart IR | Yes |
| Built-in speaker(s) | Yes |
| Audio system | 2-way |
| Signal-to-Noise Ratio (SNR) | 65 dB |
| Built-in microphone | Yes |
| Number of microphones | 2 |
| Built-in HDD | No |
| Mirror | Yes |
| Video motion detection | Yes |
| Power source type | DC |
| Power consumption (max) | 7.3 W |
| DC output voltage | 12 |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Width | 70 mm |
| Height | 69.7 mm |
| Length | 161.6 mm |
| Weight | 200 g |
| Package weight | 270 g |
| Number of cameras | 1 |
| Manual | Yes |
| Unit Calculated Weight | 0.3 kg |
| Product Net Weight | 0.2 kg |
| Unit Calculated Volume | 0.001113 cubm |
| Units per Shipping Box | 1 |
| Shipping Box Weight | 0.300000011920929 kg |
| Unit Width | 8.1 cm |
| Units per Pallet | 0 |
| Shipping Box Height | 7.90000009536743 cm |
| Unit Depth | 17.4 cm |
| Shipping Box Depth | 17.3999996185303 cm |
| Unit Height | 7.9 cm |
| Shipping Box Width | 8.10000038146973 cm |
| Name | CAMERA HDCVI 5MP IR BULLET/HFW1500RL-IL-T-0280BDIP DAHUA |
