> 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image. > Outputs max. 5 MP (2960×1668) @20 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.
> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk.
> 12 VDC/PoE power supply.
> IP67 protection.
> Sound and light alarm (red and blue lights).
> SMD 4.0.
> Supports AI SSA and one-tap arming and disarming.
> SMD area can be set in warm light areas that support triggering alarms.
> Focal Length 2.7 mm–13.5 mm. Field of View 113°–36°
Specifikacijos
| Vendor Homepage | www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizSense-Series/2-Series/Smart-Dual-Illuminators/IPC-HFW2549S-S-IL |
|---|---|
| Category Code | FNC |
| Unit Box Height | 0.14 |
| Unit Box Length | 0.15 |
| Unit Box Width | 0.34 |
| Form factor | Bullet |
| Product colour | White |
| Number of effective pixels (H x V) | 2960 (H) × 1668 (V) pixels |
| Optical sensor size | 1/2.7" " |
| Sensor type | CMOS |
| Focal length range | 2.7 mm–13.5 mm mm |
| Total megapixels | 5 MP |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Power consumption (typical) | 2.8 W |
| Operating temperature (T-T) | –30 °C to +60 °C °C |
| Depth | 94.4 mm |
| Height | 84.7 mm |
| Weight | 1050 g |
| Width | 288.4 mm |
| Lens type | Varifocal |
| Power source | 12 VDC/PoE (802.3af) |
| Suitable for outdoor use | Yes |
| Model | IPC-HFW3549T1-ZAS-PV |
| Units per Pallet | 0 |
| Units per Shipping Box | 8 |
| Unit Calculated Volume | 0.008464 cubm |
| Unit Calculated Weight | 1.41 kg |
