Engineered to handle high-intensity workloads with proven technology
Ultrastar Data Center HC555 hard drives are engineered to deliver the large capacity, strong performance and proven reliability needed to handle high-intensity workloads in 24×7 multi-user data center environments.
Handle Data Center Workloads with Proven Technology
The combination of field-proven hardware with the latest innovative technologies delivers the performance, capacity and reliability needed to handle high-intensity workloads in 24×7 multi-user data center environments.
Grow Capacity while Lowering Costs
Western Digital’s energy-assisted perpendicular magnetic recording (ePMR) technology enables customers to grow capacities while lowering TCO (total cost of ownership) including both $/TB and OpEx.
Rapid qualification and integration
Leveraging hardware designs from generations of highly successful products ensures easy qualification, seamless integration and rapid adoption by existing customers.
Reliability You Can Trust
Built off the same platform that is deployed in thousands of data centers around the world, these drives deliver superior dependability and field-proven reliability for hassle free data storage.
Increase Density with Low Power
Western Digital’s Triple-Stage Actuator (TSA) increases tracks-per-inch (TPI) while providing greater control over the actuator arm, enabling the highest capacities with low power.
Meet Eco Goals with Helium
The stable internal environment created by our HelioSeal® technology enables this high-capacity helium drive to deliver one of the lowest power profiles in the industry.
Protected Against Vibration & Shock
Disturbances caused by increased vibration are anticipated and proactively counteracted by Rotation Vibration (RV) sensors and subtle shock events are automatically detected by multi-axis shock sensors and compensated for with dynamic fly height technology to maintain performance and protect data.
Trusted Reliability, Quality and World-Class Support
As an industry-leading hard drive manufacturer, Western Digital stands behind their Ultrastar hard drives with the assurance of a projected 2.5M-hour MTBF rating.
- Capacities up to 20TB in standard 3.5-inch form factor
- Conventional Magnetic Recording (CMR) technology
- Superior reliability of field-proven hardware and firmware designs
- Seamless integration with existing applications & environments
Specifikacijos
| Summary |
Western Digital Ultrastar DC HC555. HDD capacity: 18 TB, HDD speed: 7200 RPM, Storage drive buffer size: 512 MB, HDD size: 3.5", Interface: Serial ATA III |
|---|---|
| Vendor Homepage |
https://www.westerndigital.com/en-in/products/internal-drives/data-center-drives/ultrastar-data-center-hc555-hdd?sku=0B47747 |
| Category Code |
HDC |
| 24/7 operation |
Yes |
| Average latency |
4.16 ms ms |
| Component for |
Server/workstation |
| HDD average transfer rate |
269 MB/s MB/s |
| HDD capacity |
18 TB GB |
| HDD interface transfer rate |
6 Gbit/s Gbit/s |
| HDD size |
3.5″ “ |
| HDD speed |
7200 RPM RPM |
| HDD sustained transfer rate |
257 MiB/s MiB/s |
| Hot-swap |
No |
| Interface |
Serial ATA III |
| Mean time between failures (MTBF) |
2500000 h h |
| Start/stop cycles |
600000 |
| Storage drive buffer size |
512 MB MB |
| Type |
HDD |
| Operating voltage |
5 / 12 V V |
| Power consumption (idle) |
5.3 W W |
| Power consumption (typical) |
6.4 W W |
| Non-operating shock |
250 G G |
| Non-operating vibration |
1.04 G G |
| Operating shock |
50 G G |
| Operating temperature (T-T) |
5 – 60 °C °C |
| Operating vibration |
0.67 G G |
| Storage temperature (T-T) |
-40 – 70 °C °C |
| Depth |
147 mm mm |
| Height |
26.1 mm mm |
| Weight |
679 g g |
| Width |
101.6 mm mm |
| Warranty period |
5 year(s) year(s) |
| Model name |
DC HC555 |
| Unit Calculated Volume |
0.000495 cubm |
| Unit Calculated Weight |
0.7 kg |
