Dahua Technology DHI-LM22-C201P. Display diagonal: 54.6 cm (21.5″), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Grey
Specifikacijos
| Description |
Dahua 22″ FHD LED monitor
|
|---|---|
| Vendor Homepage |
https://www.dahuasecurity.com/it/products/All-Products/Display–Control/Monitors/Commercial-Series/LM22-C201P |
| Category Code |
LC3 |
| Unit Box Height |
0.43 |
| Unit Box Length |
0.565 |
| Unit Box Width |
0.155 |
| Backlight type |
Edge LED |
| Colour depth |
8 bit |
| Colour gamut |
72% |
| Colour gamut standard |
DCI-P3 |
| Contrast ratio (typical) |
1000:1 |
| Display brightness (typical) |
250 cd/m² |
| Display diagonal |
54.6 cm (21.5″) |
| Display number of colours |
16.7 million colours |
| Display resolution |
1920 x 1080 pixels |
| Display technology |
LCD |
| HD type |
Full HD |
| Maximum refresh rate |
100 Hz |
| Native aspect ratio |
16:9 |
| Panel type |
IPS |
| Response time |
5 ms |
| Screen shape |
Flat |
| Surface hardness |
3H |
| Touchscreen |
No |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| AMD FreeSync |
No |
| Low Blue Light technology |
Yes |
| NVIDIA G-SYNC |
No |
| Built-in camera |
No |
| Built-in speaker(s) |
No |
| Feet colour |
Grey |
| Front bezel colour |
Grey |
| Product colour |
Grey |
| Audio output |
Yes |
| Built-in USB hub |
No |
| HDMI |
Yes |
| HDMI ports quantity |
1 |
| HDMI version |
1.4 |
| Headphone out |
No |
| VGA (D-Sub) ports quantity |
1 |
| On Screen Display (OSD) |
Yes |
| Panel mounting interface |
75 x 75 mm |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 – 15° |
| VESA mounting |
Yes |
| AC adapter output voltage |
12 V |
| Energy consumption (SDR) per 1000 hours |
15 kWh |
| Energy efficiency class (HDR) |
Not available |
| Energy efficiency scale |
A to G |
| Input current |
2 A |
| Power consumption (max) |
24 W |
| Power consumption (off) |
0.3 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
15 W |
| Power supply type |
External |
| Operating relative humidity (H-H) |
10 – 85% |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-10 – 50 °C |
| Depth (with stand) |
222.7 mm |
| Height (with stand) |
368.5 mm |
| Weight (with stand) |
2.64 kg |
| Width (with stand) |
492.8 mm |
| Package depth |
152 mm |
| Package height |
429 mm |
| Package type |
Box |
| Package weight |
4.14 kg |
| Package width |
561 mm |
| Cables included |
HDMI |
| Manual |
Yes |
| Power adapter included |
Yes |
| Stand included |
Yes |
| Model name |
DHI-LM22-C201P |
| Units per Pallet |
0 |
| Unit Calculated Volume |
0.03766 |
| Unit Calculated Weight |
4.1 |
