OPTIMIZED AIR FLOW
Two 120mm fans aligned vertically on the front to draw in air evenly across the entire face of the enclosure. That will contribute to positive air pressure within the case, the rising warm air will always be exhausted with the rear and top airflow from the MAG Forge 100 Series.
READY FOR OPTIMIZED MOTHERBOARD
Designed with multiple easy installation mechanisms and accommodated an up to ATX motherboard to provide an unhindered building experience.
TOOL-LESS TEMPERED GLASS
The light gray tone of 4mm tempered glass side panel is ideal for displaying RGB lighting effects and provides clear internal component construction.
The Forge 100 Series’ thoughtful case design allows users to install/remove the tempered glass easily. Simply place the tempered glass on the stump of the case before installing it for a safe and simple process.
PERSONALIZE YOUR GAMING RIG
ustomizing Addressable RGB LEDs integrated in the front, top & rear cover with a dedicated control button; or with MSI Mystic Light software, MAG Forge 100R can cast millions of colors and effects that can be synchronized with a vast ecosystem of components to augment your build.
1 to 6 ARGB LED Control Board
User can intuitively control & switch 9 lighting effects through the LED switch button.
LED Switch Button
Keep pressing the LED button for three seconds, and then users can control the lighting effects via syncing with the motherboard by MSI mystic light app.
- MSI MAG Forge 100R chassis can support up to ATX motherboard, side panel of 4mm tempered glass, up to 140 mm RGB fan, reserved cooling space and front USB 3.2 Gen 1 Type A
- Optimize Airflow
- ARGB Fan included
- 4mm Tempered Glass
- 330 mm Radiator Support
- 160 mm CPU Cooler Support
Specifikacijos
| Vendor Homepage | https://www.msi.com/PC-Case/MAG-FORGE-100R |
|---|---|
| Category Code | CAS |
| Unit Box Height | 0.485 |
| Unit Box Length | 0.57 |
| Unit Box Width | 0.27 |
| Anti-dust filter | Yes |
| Form factor | Midi Tower |
| Illumination | Yes |
| Illumination colour | Multi |
| Illumination location | Case fans |
| LED indicators | Yes |
| Material | Tempered glass |
| Maximum CPU cooler height | 160 mm |
| Maximum graphics card length | 330 mm |
| Maximum PSU length | 200 mm |
| Number of 2.5" bays | 3 |
| Number of 3.5" bays | 2 |
| Number of expansion slots | 7 |
| Number of internal 3.5" bays | 2 |
| On/off button | Yes |
| Product colour | Black/Transparent |
| Reset button | Yes |
| Side window | Yes |
| Suitable for | Gaming |
| Supported motherboard form factors | ATX/micro ATX/Mini-ITX |
| Tempered glass panel(s) | Yes |
| Type | PC |
| Power supply included | No |
| Power supply location | Bottom |
| Audio input | Yes |
| Audio output | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Front fans diameters supported | 120/140 mm |
| Front fans installed | 2x 120 mm |
| Front fans supported description | addressable RGB LED |
| Number of front fans supported (max) | 3 |
| Number of rear fans supported (max) | 1 |
| Number of top fans supported (max) | 2 |
| Rear fans diameters supported | 120 mm |
| Rear fans installed | 1x 120 mm |
| Top fans diameters supported | 120/140 mm |
| HDD/SSD combo cage | Yes |
| Supported HDD sizes | 2.5/3.5 " |
| Depth | 421 mm |
| Height | 499 mm |
| Weight | 5640 g |
| Width | 210 mm |
| Harmonized System (HS) code | 84733080 |
| Model name | MAG Forge 100R |
| Cooling & Ventilation System | Front: 2 x 120 mm addressable RGB LED Fan included, Rear: 1 x 120 mm System Fan included |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.07464 cubm |
| Unit Calculated Weight | 6.8 kg |
