White balance
ATW/Auto/Indoor/Manual/Natural/Outdoor/Sodium lamp/Street lamp
Supported graphics resolutions
1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/352 x 288/640 x 480 (VGA)/704 x 576
Bit rate
H.264: 2816Kbps - 13056Kbps; H.265: 1024Kbps - 7936Kbps
Supported network protocols
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; SSL; Qos; FTP; UPnP; ICMP; SNMP; IGMP; ARP; RTCP; RTP; PPPoE; RTMP; Bonjour; SAMBA; NFS
Intelligent Video Surveillance (IVS) system features
Abandoned object/Crossing line/Face detection/Intrusion/Missing object/Moving object/Tripwire/Vehicle detection
Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
With its powerful optical zoom, and accurate pan and tilt capabilities, this series of cameras provides a wide monitoring range and great detail. It displays images in 4 MP resolution at 25/30 fps. These cameras offer smooth control and high-grade protection that enable them to meet the requirements of video surveillance in small-sized scenes.
Starlight Technology
With advanced image processing technology and optical technology, Dahua Starlight technology can provide clear colorful video in the environment of low illuminance. It widely applies to various environments of low illuminance.
Face Detection
Dahua Face Detection technology can detect the face in the image. With deep learning algorithm, the technology supports detecting, tracking, capturing and selecting the best face image, and then outputs face snapshot.
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.
PFA Technology
PFA technology has introduced new methods of judgment that ensure the accuracy and predictability of the direction of subject distance adjustment. The result is a set of advanced focusing algorithms that ensure image clarity when zooming and that shorten focus time. This makes the camera highly advanced in its functions, substantially improving the quality of your experience.
- 1/2.8" CMOS
- Powerful 4x optical zoom
- Max.25/30fps@4M/3M
- Max 100°/s pan speed
- Supports face detection
- Support Wi-Fi
- IP66, IK10
- SMD 3.0
- 6000V lightning-proof
Specifikacijos
| Vendor Homepage | https://www.dahuasecurity.com/products/All-Products/PTZ-Cameras/Wireless-Series/Wi-Fi-Series/SD22404DB-GNY-W |
|---|---|
| Category Code | FNC |
| Unit Box Height | 0.14 |
| Unit Box Length | 0.16 |
| Unit Box Width | 0.155 |
| Form factor | Dome |
| Mounting type | Ceiling/Wall/Pole |
| Product colour | White |
| International Protection (IP) code | IP66 |
| IK code | IK10 |
| Fog proof | Yes |
| Type | IP security camera |
| Connectivity technology | Wired & Wireless |
| Placement supported | Outdoor |
| PTZ control | Yes |
| PTZ modes | 5 Pattern/8 Tour |
| PTZ protocols | Pelco-P/D |
| Tour recording | Yes |
| Preset points | Yes |
| Day/night mode | Yes |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Minimum illumination | 0.0005 lx |
| Lens viewing angle, horizontal | 90.3 - 29.4 ° |
| Lens viewing angle, vertical | 48.5 - 16.6 ° |
| Lens viewing angle, diagonal | 105.7 - 33.6 ° |
| Tilt angle range | 0 - 90 ° |
| Tilt manual speed | 0.1 - 60 °/sec |
| Tilt preset speed | 60 °/sec |
| Pan range | 0 - 355 ° |
| Pan manual speed | 0.1 - 100 °/sec |
| Pan preset speed | 100 °/sec |
| Camera shutter speed | 1 - 1/30000 s |
| Optical sensor size | 1/2.8 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Zoom capability | Yes |
| Optical zoom | 4 x |
| Digital zoom | 16 x |
| Number of lenses | 1 |
| Detect distance | 240 m |
| Observe distance | 94.8 m |
| Recognize distance | 48 m |
| Focal length range | 2.8 - 12 mm |
| Auto focus | Yes |
| Identify distance | 24 m |
| Maximum aperture number | 3 |
| Minimum aperture number | 1.6 |
| Closest focusing distance | 1.5 m |
| Night vision | Yes |
| LED type | IR |
| Maximum resolution | 2560 x 1440 pixels |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.264+/H.264B/H.264H/H.265/H.265+/M-JPEG |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 2D noise reduction,3D noise reduction |
| Gain control type | Auto/Manual |
| Back Light Compensation (BLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Highlight Compensation (HLC) | Yes |
| Image stabilizer | Yes |
| Region of Interest (ROI) encoding | Yes |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n) |
| Wi-Fi data rate (max) | 150 Mbit/s |
| Bluetooth | No |
| Number of users | 20 user(s) |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast/Unicast |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| ROM capacity | 128 MB |
| RAM capacity | 512 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Active tampering alarm | Yes |
| Video motion detection | Yes |
| Web-based management | Yes |
| Web browser | Yes |
| Power source type | DC,PoE |
| Power consumption (typical) | 2.7 W |
| Power consumption (max) | 4.8 W |
| DC output voltage | 12 |
| DC output current | 1 A |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Height | 89 mm |
| Diameter | 122 mm |
| Weight | 500 g |
| Package weight | 700 g |
| Number of cameras | 1 |
| Unit Calculated Weight | 0.77 kg |
| Product Net Weight | 0.5 kg |
| Unit Calculated Volume | 0.003472 cubm |
| Units per Shipping Box | 1 |
| Shipping Box Weight | 0.77 kg |
| Unit Width | 15.5 cm |
| Shipping Box Height | 14 cm |
| Unit Depth | 16 cm |
| Shipping Box Depth | 16 cm |
| Unit Height | 14 cm |
| Shipping Box Width | 15.5 cm |
| Name | NET CAMERA 4MP PTZ DOME WIFI/SD22404DB-GNY-W DAHUA |
| Model | SD22404DB-GNY-W |
