Supported resolutions
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Supported network protocols
HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports IP camera, DVR, NVS, etc.); P2P; Auto Registration
Certification
CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
The NVR2000-4KS3 model of the Lite Series NVR is favored for its outstanding performance. It supports 4K resolution for scenes that require highly detailed images, and can serve as the edge, central, or backup storage with an intuitive shortcut menu for remote management and control. This NVR also features Smart Motion Detection (SMD) by recorder, which can distinguish target vehicles and humans from ordinary ones in real-time. This NVR is both costeffective and easy-to-install, making it ideal for a wide range of applications such as villas, shops and other small and medium-sized scenes.
Functions
- SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and ilter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.
- Perimeter Protection by Camera
Automatically ilters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improves alarm accuracy.
- Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats
- Max. decoding capability: 6 × 1080p@30 fps
- Max. 80/80/60 Mbps incoming/recording/outgoing bandwidth
- Supports IP cameras with a resolution up to 12 MP
- AI by Recorder supports 4-channel SMD
- AI by Camera supports perimeter protection and SMD
- Supports one-click arming and disarming
Specifikacijos
| Vendor Homepage | https://www.dahuasecurity.com/products/All-Products/Network-Recorders/Lite-Series/NVR2-4KS3-Series/1HDD/NVR2104HS-4KS3 |
|---|---|
| Category Code | NVR |
| Unit Box Height | 0.31 |
| Unit Box Length | 0.33 |
| Unit Box Width | 0.09 |
| Video input channels | 4 channels |
| Video recording modes | 1080p/720p/960p |
| Maximum resolution | 3840 x 2160 pixels |
| Video motion detection | Yes |
| Audio formats supported | G.711 µ-law/G.711 A-law/G.726/PCM |
| Video formats supported | H.264/H.264+/H.265/H.265+ |
| Image formats supported | MJPEG |
| Operating system installed | Embedded LINUX |
| Input bandwidth | 80 Mbit/s |
| Output bandwidth | 60 Mbit/s |
| Wi-Fi | No |
| Maximum storage capacity | 20 TB |
| HDD interface | SATA |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10/100 Mbit/s |
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) output ports | 1 |
| Audio RCA inputs | 1 |
| Audio RCA outputs | 1 |
| eSATA ports quantity | 1 |
| Rack mounting | Yes |
| Rack capacity | 1U |
| Product colour | Black |
| Built-in processor | Yes |
| Power consumption (typical) | 10 W |
| Output current | 1.5 A |
| Output voltage | 12 V |
| Mobile operating systems supported | Android/iOS |
| Browser supported | Chrome; IE; Safari; Edge; Firefox |
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 93 % |
| Storage temperature (T-T) | -20 - 60 °C |
| Width | 260 mm |
| Depth | 232.5 mm |
| Height | 47.6 mm |
| Weight | 850 g |
| Package width | 334 mm |
| Package depth | 89 mm |
| Package height | 314 mm |
| Package weight | 1390 g |
| Unit Calculated Weight | 1.5 kg |
| Product Net Weight | 0.85 kg |
| Unit Calculated Volume | 0.01139 cubm |
| Units per Shipping Box | 10 |
| Shipping Box Weight | 15 kg |
| Unit Width | 9 cm |
| Units per Pallet | 0 |
| Shipping Box Height | 34.7000007629395 cm |
| Unit Depth | 33 cm |
| Shipping Box Depth | 92.1999969482422 cm |
| Unit Height | 31 cm |
| Shipping Box Width | 35.5999984741211 cm |
| Name | NET VIDEO RECORDER 4CH/NVR2104HS-4KS3 DAHUA |
| Model name | NVR2104HS-4KS3 |
