NVR5464-EI2
64CH 1.5U 4HDDs WizSense Network Video Recorder
> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
> Max. decoding capability: 40 × 1080p@30 fps or 10 × 8MP@30 fps.
> Max. 448/448/448 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 32 MP.
> Supports 8K HDMI output.
> Supports N+M cluster and iSCSI.
> AI by Recorder supports 4-channel face detection and recognition, up to 20 face databases and 30,000 face images; 4-channel video metadata; 8-channel perimeter protection; 16-channel SMD Plus; 4-channel AcuPick.
> AI by Camera supports face detection and recognition, perimeter protection, SMD, metadata, AcuPick, ANPR, stereo analysis, heat map, people counting, PPE detection, smart object detection and smart sound detection.
> Supports EPTZ, and one-click arming and disarming.
> Max. decoding capability: 40 × 1080p@30 fps or 10 × 8MP@30 fps.
> Max. 448/448/448 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 32 MP.
> Supports 8K HDMI output.
> Supports N+M cluster and iSCSI.
> AI by Recorder supports 4-channel face detection and recognition, up to 20 face databases and 30,000 face images; 4-channel video metadata; 8-channel perimeter protection; 16-channel SMD Plus; 4-channel AcuPick.
> AI by Camera supports face detection and recognition, perimeter protection, SMD, metadata, AcuPick, ANPR, stereo analysis, heat map, people counting, PPE detection, smart object detection and smart sound detection.
> Supports EPTZ, and one-click arming and disarming.
Specifikacijos
| Vendor Homepage | www.dahuasecurity.com/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI2-Series/4HDD/NVR5464-EI2 |
|---|---|
| Category Code | NVR |
| Unit Box Height | 0.21 |
| Unit Box Length | 0.53 |
| Unit Box Width | 0.495 |
| Alarm input channels | 16 |
| Alarm output channels | 6 |
| Video input channels | 64 channels |
| HDD interface | Serial ATA |
| Number of HDDs supported | 4 |
| Audio RCA inputs | 1 |
| Audio RCA outputs | 2 |
| eSATA | Yes |
| eSATA ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| HDMI output | Yes |
| HDMI ports quantity | 2 |
| RS-232 interface | Yes |
| RS-232 ports | 1 |
| RS-485 ports | 1 |
| USB 2.0 ports quantity | 3 |
| VGA (D-Sub) output ports | 2 |
| Operating temperature (T-T) | –10 °C to +55 °C °C |
| Storage temperature (T-T) | –20 °C to +60 °C °C |
| Depth | 415.6 mm |
| Height | 76 mm |
| Weight | 4270 g |
| Width | 440 mm |
| Model | NVR5464-EI2 |
| Units per Pallet | 0 |
| Units per Shipping Box | 2 |
| Unit Calculated Volume | 0.06306 cubm |
| Unit Calculated Weight | 7.1 kg |
