TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.
- 8× Gigabit 802.3af/at PoE+ ports and 2× Gigabit SFP slots
- 150 W total PoE budget with up to 30 W PoE output per port*
- Centralized cloud management via the web or the Omada app†
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, and IGMP Snooping
- Durable metal casing and desktop/rack mounting design
Specifikacijos
| Summary |
TP-Link Omada 10-Port Gigabit Smart Switch with 8-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE…. Power over Ethernet (PoE). Rack mounting, Form factor: 1U |
|---|---|
| Vendor Homepage |
https://www.tp-link.com/en/business-networking/omada-switch-poe/sg2210mp/ |
| Category Code |
SWI |
| Unit Box Height |
0.25 |
| Unit Box Length |
0.405 |
| Unit Box Width |
0.08 |
| ARP inspection |
Yes |
| Cloud-managed |
Yes |
| Configuring Location Settings (CLI) |
Yes |
| MIB support |
RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1213, RFC2233, RFC1643, RFC1493 |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2/L2+ |
| Switch type |
Managed |
| System event log |
Yes |
| Web-based management |
Yes |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
8 |
| SFP module slots quantity |
2 |
| 10G support |
No |
| Broadcast storm control |
Yes |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Number of VLANs |
4000 |
| Port mirroring |
Yes |
| Rate limiting |
Yes |
| Spanning tree protocol |
Yes |
| Virtual LAN features |
MAC address-based VLAN, Multicast VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| VLAN support |
Yes |
| Fiber ethernet cabling technology |
100BASE-FX, 1000BASE-X |
| Forwarding rate |
14.9 Mpps Mpps |
| Jumbo frames |
9000 |
| Jumbo frames support |
Yes |
| MAC address table |
8000 entries entries |
| Number of queues |
8 |
| Packet buffer memory |
4.1 MB MB |
| Switching capacity |
20 Gbit/s Gbit/s |
| Access Control List (ACL) |
Yes |
| BPDU filtering/protection |
Yes |
| DHCP features |
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| IGMP snooping |
Yes |
| IP-MAC-Port binding |
Yes |
| Queue scheduling algorithms |
SP, Weighted Round Robin (WRR) |
| Security algorithms |
EAP-LEAP, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS |
| SSH/SSL support |
Yes |
| Multicast support |
Yes |
| Management protocols |
SNMPv1/v2c/v3, SNTP |
| Form factor |
1U |
| Number of fans |
1 fan(s) fan(s) |
| Product colour |
Black |
| Rack mounting |
Yes |
| AC input frequency |
50/60 Hz Hz |
| AC input voltage |
100 – 240 V V |
| Power consumption (max) |
173.9 W W |
| Power source |
AC |
| Power supply included |
Yes |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Total Power over Ethernet (PoE) budget |
150 W W |
| Heat dissipation |
594.46 BTU/h BTU/h |
| Operating relative humidity (H-H) |
10 – 90% % |
| Operating temperature (T-T) |
0 – 50 °C °C |
| Storage relative humidity (H-H) |
5 – 90% % |
| Storage temperature (T-T) |
-40 – 70 °C °C |
| Depth |
180 mm mm |
| Height |
44 mm mm |
| Width |
294 mm mm |
| Certification |
CE, FCC, RoHS |
| Series |
Omada |
| Model name |
Omada 10-Port Gigabit Smart Switch with 8-Port PoE+ |
| Units per Pallet |
0 |
| Units per Shipping Box |
8 |
| Unit Calculated Volume |
0.009418 cubm |
| Unit Calculated Weight |
2.7 kg |
