Supported network protocols
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; Alarm Server;P2P
Certification
CE: EN62368-1; EN55032; EN55024; EN55035; EN61000- 3-2; EN61000-3-3; EN50130-4 FCC: Part 15 Subpart B CE- RED: EN301489-1; EN 301489-17; EN300328; EN300328; EN62311; FCC ID: 47 CFR PART 15 SUBPART C
With its embedded Wi-Fi module, Dahua's Lite Series Wireless Recorder supports the AP function, and automatically detects and connects with Dahua wireless cameras. It has two antennas that together produce strong wireless signals, and has IEEE 802.11 b/g/n (2.4G Hz) Wi-Fi which allows it to cover a wider area. This NVR also supports the access of IP cameras, making installation more convenient.Without the limitation of network cables, the wireless recorder combined with the Dahua
wireless camera provides a great solution for SMB surveillance systems, making this NVR ideal for a wide range of applications including home safety, cafes, supermarkets, retail, education and more industries.
New User Interface
Highly user friendly, the new web interface and GUI have a minimalist
flat design, that makes navigating the system much easier. The
functional modules have also been arranged to be clearer and easier to
understand.
Automatic Wireless Pairing
In just 120 seconds, the wireless NVR automatically pairs with the
wireless IPC after the system starts up, allowing you to work faster and
more efficiently.
Wireless Cascading
The wireless NVR automatically cascades IPCs for long-distance
surveillance.
- New 4.0 user interface
- One-click wireless pairing to IPCs
- Automatic pairing to IPC in 120 s after boot-up under undisturbed conditions
- Automatic cascading of IPCs for long-distance surveillance
- 4–ch@1080P (25FPS), self-adaptive decoding capability
- Supports mainstream cameras of ONVIF protocol
- Smart H.265/Smart H.264
- VGA/HDMI simultaneous video output, maximum resolution of HDMI is 1080P
- Remote configuration and management of IPCs, such as setting parameters, acquiring information and upgrading IPCs of the same model in batches
- DHCP (Dynamic Host Configuration Protocol), HTTP (Hypertext
- TransferProtocol), NTP (Network Time Protocol) and DDNS (Dynamic DomainName System)
Specifikacijos
| Vendor Homepage | https://www.dahuasecurity.com/products/ |
|---|---|
| Category Code | NVR |
| Unit Box Height | 0.115 |
| Unit Box Length | 0.37 |
| Unit Box Width | 0.305 |
| Audio codecs | PCM; G711A; G711U; G726 |
| Backup function | Yes |
| Input bandwidth | 40 Mbit/s |
| Maximum frame rate | 25 fps |
| Operating system installed | Embedded LINUX |
| Output bandwidth | 20 Mbit/s |
| Recording modes | Manual |
| Video codecs | Smart H.265; H.265; Smart H.264; H.264; MJPEG |
| Video input channels | 4 channels |
| Video motion detection | Yes |
| Video recording modes | 1080p/720p |
| HDD interface | SATA |
| Maximum storage capacity | 16 TB |
| Number of HDDs installed | 1 |
| Audio RCA inputs | 1 |
| Audio RCA outputs | 1 |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10/100 Mbit/s |
| HDMI output | Yes |
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) output ports | 1 |
| LED indicators | HDD/Network/Power |
| Product colour | Black |
| Rack capacity | 1U |
| Rack mounting | Yes |
| Built-in processor | Yes |
| Output current | 1.5 A |
| Output voltage | 12 V |
| Browser supported | Chrome; IE 9 or later; Firefox |
| Mobile operating systems supported | Android/iOS |
| Operating relative humidity (H-H) | 10 - 93 % |
| Operating temperature (T-T) | -10 - 45 °C |
| Depth | 247.3 mm |
| Height | 44.7 mm |
| Package depth | 117 mm |
| Package height | 308 mm |
| Package weight | 1560 g |
| Package width | 372 mm |
| Weight | 824 g |
| Width | 260.3 mm |
| Model | NVR1104HS-W-S2-CE |
| Model name | NVR1104HS-W-S2-CE |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.01298 cubm |
| Unit Calculated Weight | 1.6 kg |
