Supports Up to 18 Channels
Flexible access with up to 10 channels on N110 or up to 18 channels on N118, meeting different scalability needs.
Two-Way Talk in Real Time
With built-in mic and speaker, talk and listen directly through your NVR for instant communication.
Up to 4K HDMI & 1080P VGA Output
N110 and N118 support local preview, have both HDMI and VGA interfaces. HDMI supports up to 4K output, and VGA supports up to 1080P output.
4-Channel Simultaneous Playback with Multi-Speed Choices
Replay up to 4 channels(4-ch × 8MP @15fps or 4-ch × 5MP @30fps) at once and fast-forward with 2×, 4×, 8×, or 16× speeds — making event review faster and smarter.
Supports up to 16TB HDD
Supports up to 16TB HDD for extended date retention, store footage for longer time.
Supports H.265 Compression
H.265 Compression ensures smooth live view, quicker playback loading, and more days of recording with the same storage.
Works with More Devices
ONVIF conformant (Profile T), the NVR integrates seamlessly with a wide range of third-party cameras.
Specifikacijos
| Vendor Homepage | https://www.imou.com/en/product/detail/n110-n118 |
|---|---|
| Category Code | NVR |
| Unit Box Height | 0.305 |
| Unit Box Length | 0.37 |
| Unit Box Width | 0.115 |
| Audio formats supported | AAC/MP4 |
| Audio system | 2-way |
| Input bandwidth | 90 Mbit/s |
| Video formats supported | H.264/H.265 |
| Video input channels | 10 channels |
| Wi-Fi | No |
| Maximum storage capacity | 16 TB |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) output ports | 1 |
| LED indicators | Status |
| Product colour | Black |
| Reset button | Yes |
| Power consumption (max) | 19 W |
| Mobile operating systems supported | Android/iOS |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -10 - 45 °C |
| Compliance certificates | CE |
| Depth | 227.5 mm |
| Height | 45 mm |
| Weight | 850 g |
| Width | 260 mm |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45)/SATA |
| Packaging content | Screw Pack Regulatory Information Mouse |
| Quick installation guide | Yes |
| Model | NVR-N110-8A0E-P |
| Model name | N110 |
| Units per Pallet | 0 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.01298 cubm |
| Unit Calculated Weight | 1.49 kg |
