Description: Launched by Dahua Technology, Dahua WizMind is a full portfolio of solutions composed of project-oriented products including IPC, IVSS,NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer’s requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals.
Series Overview
With its deep learning algorithms, the WizMind 5 Series camera offers advanced analytical capabilities for both audio and video. It integrates intelligent features such as video metadata, AcuPick, face detection, perimeter protection, and people counting. Powered by the Xinghan Large-Scale AI Models-Vision, the camera excels in object detection, recognition, and scene adaptation. Equipped with AI-ISP imaging technology, it offers enhanced night vision performance. The series is designed for durability, being dust-proof, waterproof, and vandal-proof, in compliance with IP67 and IK10 standards, though support for these certifications may vary across models.
Xinghan Large-Scale AI Models-Vision
Xinghan Large-Scale AI Models-Vision seamlessly expands the storage and operational capacity of algorithmic models through the powerful integration of edge AI model algorithms and NPU computing power. Engineered with a lightweight transformer architecture and enhanced by model distillation and quantization techniques, it optimizes the computing power consumption of ViT operators. This enables the system to collaborate on multiple tasks simultaneously through joint inference between small and large models optimized for edge devices.
Self-Learning
Empowered by deep learning technology, the device recognizes different types of targets and their statuses through learning and analyzing target features to detect targets and filter out false alarms.
Smart Dual Light
Dahua Smart Dual Light technology adopts smart algorithm to detect targets. Usually, the IR illuminator is on at night; when the target appears in the monitoring area, the white light is on, and the camera records the full-color video and information of key events. That is, the camera links snapshot and video with full-color image. When the target is out of the monitoring area, the white light is off and the IR illuminator is on, which reduces light pollution efficiently.
AcuPick
This industry-leading search technology effectively utilizes both front-end and back-end intelligence to help with searching through massive video data to quickly and conveniently locate targets with greater precision.
Protection (IP67, Wide Voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
Long Description: Dahua Technology WizMind 8MP Smart Dual Light Fixed-focal Bullet Network Camera. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 110°, Lens viewing angle, vertical: 56°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8″). Detect distance: 89.2 m, Observe distance: 35.7 m, Recognize distance: 17.8 m
Vendor Homepage: https://www.dahuasecurity.com/mena/products/All-Products/Network-Cameras/WizMind-5-Series/Smart-Dual-Light/8MP/IPC-HFW5859E-ASE-IL
CnCode: 85258900
Bullet Points:
- 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image
- Outputs max. 8 MP (3840 × 2160) @25/30 fps
- Built-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m
- ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions
- With deep learning algorithm, it supports: AcuPick, video metadata, IVS, face detection, and people counting, etc
- Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1 TB Micro SD card; built-in Mic
- 12 VDC/PoE power supply; ePoE
- IP67 protection
Form factor: Bullet
Power source type: DC
Type: IP security camera
Power consumption (typical): 4.2
Power consumption (max): 13.3
Power consumption (Power over Ethernet (PoE)): 6.3
DC output voltage: 12
Connectivity technology: Wired
Built-in HDD: No
Number of cameras: 1
Ethernet LAN (RJ-45) ports: 1
Card reader integrated: Yes
Ethernet LAN: Yes
Maximum resolution: 3840 x 2160
Placement supported: Indoor & outdoor
Ethernet interface type: Fast Ethernet
Night vision: Yes
PTZ control: Yes
Networking standards: IEEE 802.3at
PTZ modes: Digital PTZ
Web browser: Yes
Compatible memory cards: MicroSD (TransFlash)
Supported network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P
Maximum memory card size: 1000
Wi-Fi: No
Night vision distance: 50
Minimum illumination: 0
Wi-Fi standards: Not supported
Mounting type: Ceiling/Wall/Pole
Product colour: White
Bluetooth: No
LED type: IR/White
Housing material: Metal
Cabling technology: 10/100Base-T(X)
Audio input channels: 1.0
Total megapixels: 8
Number of illumination LEDs: 4
Audio output channels: 1.0
Audio codecs: G.711a; G.711Mu; PCM; G.726; G.723
Video compression formats: H.264/H.264B/H.264H/H.265/M-JPEG
Alarm input channels: 1
Supported graphics resolutions: 3840 x 2160
Number of lenses: 1
International Protection (IP) code: IP67
Alarm output channels: 1
Supported video modes: 2160p
Frame rate: 30
Optical sensor size: 1/1.8
Width: 70.5
Operating temperature (T-T): -40 – 60
Signal-to-Noise Ratio (SNR): 56
Mobile operating systems supported: Android/iOS
Video streaming: Yes
Storage temperature (T-T): -40 – 60
Built-in microphone: Yes
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Detect distance: 89.2
Observe distance: 35.7
Fog proof: Yes
Recognize distance: 17.8
People counting function: Yes
Height: 66.4
Operating relative humidity (H-H): 0 – 95
ROM capacity: 4000
Wide Dynamic Range (WDR): Yes
Length: 192.7
Day/night mode: Yes
Alarm input/output: Yes
Angle of rotation: 360
Built-in light: Yes
Lens viewing angle, horizontal: 110
Storage relative humidity (H-H): 0 – 95
Lens viewing angle, vertical: 56
Lens viewing angle, diagonal: 134
Progressive scan: Yes
Tilt angle range: 0 – 90
Fixed focus: Yes
Pan range: 0 – 360
Gain control type: Auto/Manual
Identify distance: 8.9
Maximum aperture number: 1.6
Data transfer rate: 100
Iris: Yes
Lens mount interface: M12
Weight: 610
Intelligent Video Surveillance (IVS) system features: Face detection/Heat map/Intrusion/Moving object/Tripwire
Mirror: Yes
Privacy protection: Yes
Video motion detection: Yes
RAM capacity: 2000
Client interoperability: ONVIF (Profile S & Profile G & Profile T & Profile M); CGI
Back Light Compensation (BLC): Yes
Bit rate: 3 kbps-16384 kbps
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC): Yes
Region of Interest (ROI) encoding: Yes
Closest focusing distance: 2.1
Fixed focal length: 2.8
Sensor type: CMOS
White balance: Auto/Manual/Natural/Outdoor/Regional custom/Street lamp
Dynamic range: 120
Camera shutter type: Electronic/Mechanical
Camera shutter speed: 1/3 – 1/100000
Management software: DSS; DMSS; DoLynk Care
Package weight: 770
Certification: CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
Units per Shipping Box: 1
Unit Calculated Volume: 0.003758
Unit Calculated Weight: 0.75
